6ES7350-2AH01-0AE0
MPN6ES7350-2AH01-0AE0
End of Life
SIMATIC S7-300, Counter module FM 350-2, 8 channels, 20 kHz, 24 V encoder for counting, frequency measurement, speed measurement, period duration measurement, dosing incl. configuration package and electronic documentation on CD-ROM
$777.77 – $1,662.00Ref. price · indicative, final on quote
StockContact for availability
Lead timeCall for availability wk
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
I/O
| Parameter | Value |
|---|---|
| Digital inputs | 8 |
| Digital outputs | 8 |
Electrical
| Parameter | Value |
|---|---|
| Rated value (DC) | 24 V |
| Permissible range, lower limit (DC) | 20.4 V |
| Permissible range, upper limit (DC) | 28.8 V |
| For signal "1" | 11 to 30.2 V |
| For signal "0" | -3 to +5V |
| Current for signal "1" (typ.) | 9 mA |
| Power loss (typ.) | 10 W |
| Current consumption from backplane bus (5 V DC), max. | 100 mA |
| Current consumption from load voltage L+ (no load), max. | 150 mA |
| Short-circuit protection | Yes |
| Isolation: channels to backplane bus | Yes; and shielding |
| Max. cable length, shielded | 600 m |
| Max. cable length, unshielded | 100 m |
Performance
| Parameter | Value |
|---|---|
| Diagnostic alarm | Yes; Parameterizable |
| Diagnostics function | Yes; Diagnostic information readable |
| Group fault indicator (SF, red LED) | Yes |
Mechanical
| Parameter | Value |
|---|---|
| Height | 125 mm |
| Width | 80 mm |
| Depth | 120 mm |
| Weight (approx.) | 460 g |
MPN
6ES7350-2AH01-0AE0
