ABB 1SDA058232R1 — Molded Case Circuit Breakers (MCCB)

ABB 1SDA058232R1 EMAX Rating Plug, 4000A, IEC/UL

MPN1SDA058232R1

ABB, EMAX series, rating plug, 1SDA058232R1, 4000 A, for - frames, IEC and UL listed.

$36.83Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

1SDA058232R1 — Specifications
ParameterValue
Weight0.45 kgs

Product details

Rating plug for EMAX E4/E6 — 4000 A, IEC and UL

The ABB 1SDA058232R1 is a rating plug for the EMAX and air circuit breaker frames, set for 4000 A continuous current. It carries both IEC and UL certifications, so it slots into panels built to either standard without a separate North American variant. Classified under Connectors / Electrical Plugs & Receptacles, but functionally it's a breaker accessory — the plug mates with the EMAX trip unit, not a panel connector.

Frequently asked questions

Where can I buy 1SDA058232R1 and how do I get a price?

Sourced and quoted to order against an RFQ through independent distribution. Submit a request for current pricing and availability — no stock count or lead-time number is published here.

What does the 4000 A rating mean for breaker coordination?

The plug sets the continuous current rating (In) of the EMAX or breaker to 4000 A. That determines the pickup threshold for overload and short-circuit protection — match it to the downstream load's full-load amps for proper selectivity.

What compliance documentation does ABB provide for 1SDA058232R1?

The plug carries both IEC and UL listings per the description — meaning it meets the relevant product standards for those jurisdictions. RoHS and REACH compliance documentation would be included with the shipment from ABB's standard package.

MPN
1SDA058232R1
