ABB PSR37-600-11 softstarter, 37 A, 208-600 V AC, voltage ramp soft start, 24 V AC/DC control.
| Parameter | Value |
|---|---|
| Terminal type | Screw Terminals |
| Product main type | PSR37 |
| Voltage | 208 ... 600 V AC |
| Initial voltage during start | 40 ... 70 % |
| Step down voltage special ramp | 100 ... 60 % |
| Rated control supply voltage | 24 V AC/DC |
| Rated control circuit voltage | 24 V DC |
| Technical UL (CSA, maximum operating voltage UL, CSA) | Main Circuit 600 V |
| Current limit function | No |
| Starting capacity at maximum rated current ie | 4xIe for 6s |
| Rated operational current - In-Line connection | 37 A |
| Technical UL (CSA, horsepower rating UL, CSA) | (200 ... 208 V AC) Three Phase 10 Hp |
| Parameter | Value |
|---|---|
| Rated operational power - In-Line connection | (230 V) 7.5 kW |
| Rated frequency | 50/60 Hz |
| IP rating | acc. to IEC 60529, IEC 60947-1, EN 60529 Main Terminals IP10 |
| Protocol | FiledBusPlug(Optional) |
| Switch for inside delta connection | No |
| Popular downloads (CAD dimensional drawing) | 2CDC001079B0201 |
| Material compliance (Toxic substances control act - TSCA) | 2CMT2023-006524 |
| Material compliance (Conflict minerals reporting template) | 9AKK108467A5658 |
| Technical UL (CSA, tightening torque UL, CSA) | Control Circuit 5.3 in·lb |
| Function | Soft start with voltage ramp |
| Ramp time | 0 ... 20 second [unit of time] |
| Run signal relay | Yes |
| Tightening torque | Control Circuit 0.6 N·m |
| Fault signal relay | No |
| Overload protection | Recommended MS450 28 ... 40 |
| By-pass signal relay | Yes |
| Overload signal relay | No |
| Ambient air temperature | Operation -25 ... +60 °C |
| Service factor percentage | 100 % |
| Object classification code | Q |
| Popular downloads (EPLAN data) | 9AAC129853_EPLAN |
| Integrated electronic overload | No |
| Connecting capacity main circuit | Rigid 1x 6 ... 35 mm² |
| Signal indication running r | Green |
| Connecting capacity supply circuit | Rigid 1 x 0.75 ... 2.5 |
| IDEA granular category code | 4740 >> Soft starter |
| Connecting capacity control circuit | 1 x 0.75 ... 2.5 mm² |
| Signal indication ramping up (Down) | Green |
| Popular downloads (Instructions and manuals) | 1SFC132078M9901 |
| Signal indication completed start ramp | Green |
| Popular downloads (Data sheet, technical information) | 1SFC132012C0201 |
| Popular Downloads/Instructions and manuals (Part 3) | 1SFC132060M0201 |
The 1SFA896110R1100: ABB PSR37-600-11 softstarter rated at 37 A for 208-600 V AC three-phase motors. Uses voltage ramp soft start with adjustable ramp time from 0 to 20 seconds and initial voltage 40-70% of line. Control supply is 24 V AC/DC via screw terminals. Recommended overload protection is the MS450 set to 28-40 A range.
RoHS compliant following EU Directive 2011/65/EU and Amendment 2015/863. WEEE category 5 (small equipment). No UL/CSA documentation specifics are listed beyond horsepower rating at 200-208 V AC (10 HP).
