ABB 3AXD50000050056 — Inverter / VFD

3AXD50000050056 ACS880-04XT-1580A-7 Drive Module, Frame 1000

MPN3AXD50000050056
Active

ABB ACS880-04XT-1580A-7 drive module, Frame Size 1000, SCIP 38EAC3ED-6729-45A3-99A3-F7FA089E57C4 Finland, WEEE Category 4.

Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

3AXD50000050056 specifications
ParameterValue
Frame size1000
SCIP38EAC3ED-6729-45A3-99A3-F7FA089E57C4 Finland
Ecodesign exemptionEnergy efficiency data is not provided for the drive module/module package. The drive modules/module packages are not considered as VSD and are not in the scope of the EU ecodesign requirements (Regulation EU/2019/1781).

Product details

The ABB 3AXD50000050056 is the ACS880-04XT-1580A-7 drive module, rated for 1580 A output. Frame Size 1000 means it's a large chassis requiring dedicated panel space and a crane or lift for installation. It's listed as current and productStatus Active — still a valid BOM line for new builds and spares.

SCIP number 38EAC3ED-6729-45A3-99A3-F7FA089E57C4 Finland is on file — that's the EU SCIP database entry for substances of concern, required for ECHA compliance. The module carries a WEEE Category 4 classification (Large Equipment, any external dimension >50 cm), which governs end-of-life take-back obligations in EU markets. The Ecodesign Exemption note states that energy-efficiency data is not provided for this drive module because it's not considered a VSD under EU 2019/1781. That's a regulatory carve-out, not a missing spec — the module is exempt from the efficiency reporting requirement.

Frequently asked questions

What is the SCIP number for this module?

The SCIP number is 38EAC3ED-6729-45A3-99A3-F7FA089E57C4 Finland, registered for EU substance-of-concern reporting.

What frame size is this drive module?

Frame Size 1000 — a large, cabinet-mounted chassis requiring mechanical handling provisions.

MPN
3AXD50000050056
