Schneider Electric 13515
MPN13515
Obsolete
extra neutral bar for distribution terminal block - 100 A
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Product / component type | Extension module |
| Range of product | Prisma PH Canalis KV Prisma G Prisma P Prisma GX |
| Parameter | Value |
|---|---|
| Rated insulation voltage [Ui] | 500 V AC |
| Poles description | 1N |
| Parameter | Value |
|---|---|
| Connections / terminals | Cable6...16 mm² semi-rigid |
| Mounting support | 35 mm symmetrical DIN rail Multifix rail |
| Parameter | Value |
|---|---|
| Pollution degree | 3 |
| Parameter | Value |
|---|---|
| Standards | EN 60947-7-1 |
| Parameter | Value |
|---|---|
| Busbar length | 62 mm |
| Kit composition | Open screws Insulating back Cover |
| Distribution block outgoers | 4 x 7 holes |
| [Ie] rated operational current | 100 A |
| Accessory (separate part category) | Connection accessories |
| [Ipk] rated peak withstand current | 20 kA |
| [Icw] rated short-time withstand current | 3.5 kA for 1 s |
| Comb busbar, distribution terminal block accessory type | Neutral bar |
MPN
13515
