Schneider Electric Modicon Quantum automation platform 140DDO84300 DC discrete output module, 16 points, 10-60 V DC, positive logic (source), 2 A per point, 8 A per group fuse, chassis mount, CE, UL 508, CSA, FM Class 1 Div 2.
| Parameter | Value |
|---|---|
| Protection type | Internal output protection by 8 A fuse per group |
| Range of product | Modicon Quantum automation platform |
| Product or component type | Dc discrete output module |
| Maximum voltage drop | <1 V 2 A |
| Output voltage limits | 10.2...72 V |
| Discrete output voltage | 10...60 V DC |
| Surge current | 7.5 A 50 s |
| Maximum load current | 12 A per module 6 A per group |
| Bus current requirement | 160 mA |
| Maximum leakage current | 1 mA 60 V |
| Power dissipation | 1 W + (1 V x total module load current) |
| Response time | <= 1 ms at state 1 to state 0 |
| Parameter | Value |
|---|---|
| Relative humidity | 95 % without condensation |
| Operating altitude | <= 16404.2 ft (5000 m) |
| Standards | CSA C22.2 No 142 UL 508 |
| Marking | CE |
| Category | US1PC2118155 |
| Module format | Standard |
| Load inductance | Inductance(H) = 0.5/((current(A))² x (switching frequency(Hz))) |
| Local signalling | 1 LED (green) for bus communication is present (Active) 1 LED (red) for external fault detected (F) 16 LEDs (green) for input status |
| Group of channels | 2 groups of 8 |
| Discrete output logic | Positive logic (source) |
| Addressing requirement | 1 output word |
| Associated fuse rating | 2 A each point 8 A per group |
| Discrete output number | 16 |
| Absolute maximum output | 72 V permanent |
| Isolation between group | 700 Vrms DC for 1 minute |
| Isolation between channels and bus | 2500 Vrms DC for 1 minute |
| Ambient air temperature for storage | -40...185 °F (-40...85 °C) |
| Resistance to electromagnetic fields | 9.1 V/m (10 V/m) 80...2000 MHz IEC 801-3 |
| Ambient air temperature for operation | 32...140 °F (0...60 °C) |
| Resistance to electrostatic discharge | 4 kV contact IEC 801-2 8 kV on air IEC 801-2 |
The 140DDO84300 is a Modicon Quantum DC discrete output module delivering 16 sourcing (positive-logic) points across two isolated groups, each point rated 2 A and each group fused at 8 A. Output voltage range is 10 to 60 V DC with a permanent absolute maximum of 72 V; the module occupies one output word in the backplane and draws 1.0 W from the rack.
