Schneider Electric 140NOE77101

Schneider Modicon 140NOE77101 Ethernet TCP/IP Module, Obsole

MPN140NOE77101
Obsolete

Schneider Electric Modicon Quantum 140NOE77101 Ethernet TCP/IP module, 10/100 Mbit/s, dual physical interface (MT/RJ fiber and RJ45 copper), Modbus TCP/IP communication, Transparent Ready concept, hot standby redundancy, Class B30 web server, CSA and FM Class 1 Div 2 listed.

$1,909.43 – $1,993.00Ref. price · indicative, final on quote
Schneider Electric 140NOE77101 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

140NOE77101 key specifications
ParameterValue
Range of productModicon Quantum automation platform
Product or component typeEthernet network TCP/IP module
Current consumption750 mA 5 V DC
IP degree of protectionIP20
Physical interfaceMT/RJ - 100BASE-FX fiber optic RJ45 - 10BASE-T/100BASE-TX twisted pair
Communication serviceSNMP network management Bandwidth management Global Data I/O scanning Modbus TCP messaging FDR server
Communication port protocolEthernet Modbus TCP/IP
Relative humidity95 % without condensation
Operating altitude<= 14763.78 ft (4500 m)
StandardsCSA C22.2 No 142 FM Class 1 Division 2
SupplyVia the power supply of the rack
ConceptTransparent Ready

All specifications

140NOE77101 additional specifications
ParameterValue
MarkingCE
CategoryUS1BMS180230
RedundancyYes hot standby redundant architecture
Web serverClass B30
Web servicesDiagnostics via predefined web pages Rack viewer Data Editor (via PC terminal)
Module formatStandard
Local signalling1 LED for 10 Mbps or 100 Mbps data rate (10 MB/100 MB) 1 LED for collision detection (Coll) 1 LED for download mode (Kernel) 1 LED for Ethernet module fault (Fault) 1 LED for Ethernet network status (RUN) 1 LED for full-duplex mode (Fduplex) 1 LED for module ready (Ready) 1 LED for network active (Link) 1 LED for rack operational (Active) 1 LED for transmission/reception activity (TxAct/RxAct)
Transmission rate10/100 Mbit/s
Ambient air temperature for storage-40...185 °F (-40...85 °C)
Resistance to electromagnetic fields9.1 V/m (10 V/m) 80...1000 MHz IEC 801-3
Ambient air temperature for operation32...140 °F (0...60 °C)
Resistance to electrostatic discharge4 kV contact IEC 801-2 8 kV on air IEC 801-2

Product details

Functional Overview

The 140NOE77101 is a Quantum Ethernet network TCP/IP module that performs Modbus TCP/IP messaging, I/O scanning, global data exchange, and SNMP network management. It supports a hot standby redundant architecture for fault-tolerant control. The module draws 750 mA from the 5 V rack supply and operates at 10/100 Mbit/s over either 100BASE-FX fiber (MT/RJ connector) or 10BASE-T/100BASE-TX twisted pair (RJ45).

Compliance and Hazardous Location

The module carries CE marking and is certified to CSA C22.2 No 142, as well as FM Class 1 Division 2 for use in classified hazardous locations. It withstands electrostatic discharge per IEC 801-2 at 4 kV contact / 8 kV air and electromagnetic fields per IEC 801-3 up to 10 V/m. Rated for operation in 0 °C to 60 °C ambient with 95 % relative humidity non-condensing, and storage from -40 °C to 85 °C. Maximum operating altitude is 4500 m.

Sourcing Status — Obsolete

Schneider Electric has declared the 140NOE77101 obsolete. No direct replacement order code is listed. This unit is available only through surplus, last-time-buy, or broker supply channels. The full declaration of conformity package can be supplied upon RFQ to satisfy supplier-quality documentation requirements.

Frequently asked questions

What compliance documentation does Schneider provide for this module?

This module carries CE marking, CSA C22.2 No 142 certification, and FM Class 1 Division 2 listing for hazardous locations. RoHS/REACH declarations are not in the spec record but can be requested in the RFQ.

What is the supply requirement for the 140NOE77101?

The module draws 750 mA from the 5 V DC backplane supply of the Quantum rack; no external power connection is needed.
