Schneider Electric 174CEV20040
MPN174CEV20040
Obsolete
SQD 174CEV20040 CONNEXIUM|SQD 174CEV20040 CONNEXIUM MB+/ETHERNET BRIDGE
$3,429.00Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Control type | Local/remote control |
| Product or component type | Ethernet/Modbus Plus gateway/router |
| Supply voltage limits | 93.5...242 V AC |
| Supply voltage | 110 V AC 220 V AC |
| Current consumption | 1 A |
| Supply frequency | 47...63 Hz |
| IP degree of protection | IP20 |
| Communication gateway | Ethernet/Modbus Plus |
| Communication port protocol | Ethernet TCP/IP 10BASE-T/100BASE-TX twisted shielded pairs cable 10/100 Mbit/s Modbus Plus HDLC synchronous RS485 twisted shielded pairs cable (single or double) 1 Mbit/s |
| Electrical connection | 1 cable - twisted shielded pairs cable (single or double) <328.08 ft (100 m) ETHERNET |
| Relative humidity | 10...95 % without condensation |
| Depth | 9.8 in (248 mm) |
All specifications
| Parameter | Value |
|---|---|
| Width | 4.8 in (122 mm) |
| Height | 9.02 in (229 mm) |
| Concept | Transparent Ready |
| Marking | CE |
| Category | 30268-CONNEXIUM ETHERNET SOLUTIONS |
| Web services | Diagnostic via predefined web pages Predefined web pages configuration Read/write |
| Level or class | Class B10 |
| Ethernet service | Modbus TCP messaging SNMP agent |
| Local signalling | 1 LED for RUN |
| Ambient air temperature for operation | 32...122 °F (0...50 °C) |
MPN
174CEV20040
