Schneider Electric A9K12463

Schneider Electric A9K12463 Acti9 K60H MCB, 63A 4P C-Curve,

MPN A9K12463
Active

Schneider Electric Acti9 K60H, A9K12463, miniature circuit breaker, 63 A, 4P, C-curve, 10 kA Icn at 400 V AC, DIN rail mount, thermal-magnetic trip.

Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

A9K12463 key specifications
ParameterValue
Control typeToggle
Trip unit typeThermal-magnetic
Main product or component typeMiniature circuit-breaker
Insulation voltage ui440 V AC 50/60 Hz
Breaking capacity10000 A Icn at 400 V AC 50/60 Hz conforming to EN/IEC 60898-1
IP ratingIP20
Temp storage max85 °C
Temp storage min-25 °C
Temp operating max70 °C
Temp operating min-25 °C
Storage temperature-25...85 °C
ColorWhite

All specifications

A9K12463 additional specifications
ParameterValue
Depth70 mm
Width72 mm
Height81 mm
Electrical life cycles10000 cycles
Mechanical life cycles20000 cycles
ApplicationDistribution
Operating temperature-25...70 °C

Product details

What this 63 A 4P MCB delivers in the panel

The Schneider Electric A9K12463 is a 63 A, 4-pole miniature circuit breaker from the Acti9 K60H series, built for distribution boards where you need a C-curve trip (magnetic release at 5 to 10 times In) and a 10 kA breaking capacity at 400 V AC per EN/IEC 60898-1. Rated 63 A continuous, it carries a 4-pole (4P) configuration — switching all four poles simultaneously, with the neutral pole protected. That's what you want for a three-phase + N distribution circuit where you need full isolation and overcurrent protection on the neutral as well. The 440 V rated insulation voltage (Ui) keeps it within standard 400 V three-phase networks.

The tunnel-type terminals accept 0.5 to 35 mm² rigid copper on both top and bottom, with a 14 mm wire strip length and 3.5 N·m tightening torque. That's a generous wire range for a 63 A breaker — you can land a 35 mm² feeder directly without a ferrule or reducer. IP20 finger-safe terminals are standard for enclosed panels; no touch-protection concern inside a closed distribution board.

The C-curve's 5-10x In magnetic threshold (315 to 630 A for a 63 A unit) is wide enough to ride through motor starting currents on small pumps or fans, yet fast enough to clear a hard short. For a commissioning engineer checking coordination: pair this with a 100 A or 125 A gG fuse or a higher-rated Acti9 MCB upstream, and you'll likely get full selectivity up to the 10 kA fault level.
