Schneider Electric ABE7H12R11

Schneider ABE7H12R11 Modicon ABE7 passive I/O sub-base, 12 channels, discontinue

MPNABE7H12R11
Obsolete

Schneider ABE7H12R11 Plc Expansion Modules — now discontinued, supplied from remaining surplus and broker stock.

$295.00Ref. price · indicative, final on quote
Schneider Electric ABE7H12R11 datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

ABE7H12R11 key specifications
ParameterValue
Sub-base typeI/O sub-base
Connector typeHE-10
Range of productModicon ABE7
Supply voltage typeDC
Product or component typePassive discrete I/O sub-base
Supply voltage19...30 V IEC 61131-2
Voltage2000 V
Voltage drop on power supply fuse0.2 V
Current per channel0.5 A
Maximum supply current6.1 A
Short-circuit protection6.3 A internal fuse, 5 x 20 mm, fast blow PLC end)
Maximum current per output common6.1 A

All specifications

ABE7H12R11 additional specifications
ParameterValue
IP degree of protectionIP2X conforming to IEC 60529
Installation categoryII IEC 60664-1
Connections - terminalsScrew type terminals, 1 x 0.09...1 x 1.5 mm² AWG 28...AWG 16) flexible with cable end Screw type terminals, 1 x 0.14...1 x 2.5 mm² AWG 26...AWG 12) solid Screw type terminals, 1 x 0.14...1 x 2.5 mm² AWG 26...AWG 14) flexible without cable end Screw type terminals, 2 x 0.09...2 x 0.75 mm² AWG 28...AWG 20) flexible with cable end Screw type terminals, 2 x 0.2...2 x 2.5 mm² AWG 24...AWG 14) solid
Number of terminal per channel1
Resistance to incandescent wire1382 °F (750 °C) IEC 60695-2-11
Pollution degree2 IEC 60664-1
Shock resistance15 gn 11 ms IEC 60068-2-27
Vibration resistance2 gn (f= 10...150 Hz) conforming to IEC 60068-2-6
Width4.9 in (125 mm)
Category22375-INTERFACE MODULE(ABA,R,S)
Pin number20 pins
Status LED1 LED per channel (Green) channel status 1 LED (Green) power ON
Fixing modeBy clips (35 mm symmetrical DIN rail) By screws (solid plate with fixing kit)
Tightening torque5.3 lbf.in (0.6 N.m) flat Ø 3.5 mm
Channels12
Polarity distributionNo
Number of horizontal rows1
Resistance to fast transients2 kV level 3 IEC 61000-4-4
Resistance to radiated fields9.1 V/m (10 V/m) 26000000...1000000000 Hz)IEC 61000-4-3 level 3
Ambient air temperature for storage-40...176 °F (-40...80 °C) IEC 61131-2
Ambient air temperature for operation23...140 °F (-5...60 °C) IEC 61131-2
Resistance to electrostatic discharge4 kV contact) level 3 IEC 61000-4-2 8 kV air) level 3 IEC 61000-4-2

Product details

Overview

The ABE7H12R11 is a Modicon ABE7 passive connection sub-base that routes 12 discrete I/O channels from a 20-pin HE-10 connector to screw terminals, rated for a maximum of 6.1 A with a 6.3 A internal fast-blow fuse protecting the field side.

Schneider discontinued the ABE7H12R11 on 2023-10-18; remaining units are available through surplus and broker channels only.
