Schneider ATV212HU15M3X Motor Drives — now discontinued, supplied from remaining surplus and broker stock.
| Parameter | Value |
|---|---|
| Rated supply voltage | 200...240 V - 15...10 % |
| Parameter | Value |
|---|---|
| Motor power (normal / heavy duty) | 1.5 kW |
| Parameter | Value |
|---|---|
| Compliance standards | IEC 61800-5-1 IEC 61800-3 environments 2 category C1 IEC 61800-5-1 IEC 61800-3 environments 1 category C1 UL Type 1 IEC 61800-3 environments 2 category C2 IEC 61800-3 environments 2 category C1 IEC 61800-3 IEC 61800-3 environments 1 category C2 IEC 61800-3 IEC 61800-3 environments 2 category C3 IEC 61800-3 environments 1 category C3 IEC 61800-3 environments 1 category C2 IEC 61800-3 environments 2 category C3 IEC 61800-3 environments 1 category C1 IEC 61800-3 environments 1 category C3 IEC 61800-3 environments 2 category C2 |
| Parameter | Value |
|---|---|
| Height | 5.6 in (143 mm) |
| Width | 4.2 in (107 mm) |
The ATV212HU15M3X is a Schneider Altivar 212 AC drive rated 1.5 kW / 2 hp with a 7.5 A continuous output on a 3-phase supply, built for simple variable-speed motor control in HVAC and light industrial applications. It carries a LonWorks communication card as standard, supports Modbus, BACnet, METASYS N2, and APOGEE FLN over its RS-485 port, and includes an adjustable PI regulator for closed-loop process control.
