Schneider Electric BMENOC0321C

Schneider BMENOC0321C M580 Control Router

MPNBMENOC0321C
Obsolete

Control Router

$1,461.77 – $3,683.00Ref. price · indicative, final on quote
Schneider Electric BMENOC0321C datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

BMENOC0321C key specifications
ParameterValue
Range of productModicon M580
Product or component typeCommunication module
Integrated connection type3 Ethernet RJ45 10/100/1000 Mbps double shielded twisted pair
Current consumption1800 mA 3.3 V DC
IP degree of protectionIP20
Communication serviceBandwidth management FDR server Modbus TCP I/O Scanner and Messaging Ethernet/IP I/O Scanner and Messaging RSTP support IP forwarding Email
StandardsIEC 61131-2 IEC 61010-2-201 UL 61010-2-201 CSA C22.2 No 61010-2-201 IACS E10 IEC 61000-6-5, interface type 1 and type 2 IEC 61850-3, location G IEC 60079-0
SupplyInternal power supply via rack
MarkingCE
CategoryUS1PC3418160
Directives2014/35/EU - low voltage directive 2014/30/EU - electromagnetic compatibility 2014/34/EU - ATEX directive
Web serverAdvanced

All specifications

BMENOC0321C additional specifications
ParameterValue
Memory usageApplication saving Activating the advanced web server
Web servicesFactoryCast configurable
Local signalling1 LED (green) for processor running (RUN) 1 LED (red) for processor or system fault (ERR) 1 LED (green/red) for ETH MS (Ethernet port configuration status) 1 LED (green/red) for Eth NS (Ethernet network status) 1 LED (green/red) for Eth NS1 (Ethernet network status) 1 LED (green/red) for Eth NS2 (Ethernet network status)
Protective treatmentConformal coating
Transmission support mediumEthernet backplane
Environmental characteristicGas resistant class Gx ISA S71.04 Gas resistant class 3C4 IEC 60721-3-3 Dust resistant class 3S4 IEC 60721-3-3 Sand resistant class 3S4 IEC 60721-3-3 Salt resistant level 2 IEC 68252 Mold growth resistant class 3B2 IEC 60721-3-3 Fungal spore resistant class 3B2 IEC 60721-3-3 Hazardous location class I division 2
Ambient air temperature for operation32...140 °F (0...60 °C)
MPN
BMENOC0321C
