Schneider Electric BMXDDM16022H

Schneider BMXDDM16022H Modicon X80 Discrete I/O, 8-in 8-out,

MPNBMXDDM16022H
Active

Schneider Modicon X80, Discrete I/O Module, 8 Input 24VDC, 8 Output Solid-State, Severe Environment, BMXDDM16022H.

$193.04 – $438.00Ref. price · indicative, final on quote
Schneider Electric BMXDDM16022H datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

BMXDDM16022H key specifications
ParameterValue
Input typeCurrent sink (logic positive)
Range of productModicon X80
Discrete output typeSolid state
Product or component typeDiscrete I/O module
Discrete input voltage24 V DC, discrete input logic: positive
Discrete output voltage24 V 19...30 V DC at 60 °C 24 V 26.4 V DC at 70 °C
Current consumption= 48 Ohm
Discrete input current3.5 mA
Discrete output current0.5 A
Current state 0 guaranteed10 MOhm 500 V DC
Current state 1 guaranteed>= 3 mA
Typical current consumption79 mA at 3.3 V DC 59 mA at 24 V DC

All specifications

BMXDDM16022H additional specifications
ParameterValue
Sensor power supply21.1...29.0 V 70 °C 19...30 V 60 °C
Power dissipation in3.7 W
IP degree of protectionIP20
Response time on output1.2 ms
DC maximum response time7 ms
DC typical response time4 ms
Shock resistance30 gn
Relative humidity5...95 % at 55 °C without condensation
Operating altitude0...2000 m 2000...5000 m with derating factor
Vibration resistance3 gn
Directives2014/35/EU - low voltage directive 2014/30/EU - electromagnetic compatibility
Status LED1 LED (green) module operating (RUN) 1 LED per channel (green) channel diagnostic 1 LED (red) module error (ERR) 1 LED (red) module I/O
Dielectric strength1500 V AC at 50/60 Hz 1 minute, output/ground 1500 V AC at 50/60 Hz 1 minute, output/internal logic 1500 V AC at 50/60 Hz 1 minute, primary/secondary 500 V DC 1 minute, between group of inputs and outputs
Input compatibilityWith 2-wire/3-wire proximity sensors conforming to IEC 60947-5-2 With 2-wire/3-wire proximity sensors conforming to IEC 61131-2 type 3
Protective treatmentConformal coating
Discrete input number8
Discrete output number8
Paralleling of outputsYes : 2 maximum
Environmental characteristicGas resistant class Gx Gas resistant class 3C4 Dust resistant class 3S4 Sand resistant class 3S4 Salt resistant level 2 Mold growth resistant class 3B2 Fungal spore resistant class 3B2
Product specific applicationFor severe environments
Ambient air temperature for storage-40...85 °C
Ambient air temperature for operation-25...70 °C

Product details

The BMXDDM16022H: 8 inputs at 24 V DC sink logic and 8 solid-state outputs at 0.5 A each, conformal-coated for severe environments. Mounts in a Modicon X80 rack. IP20-rated enclosure.

Conformal coating pre-applied. Outputs can be paralleled up to two channels. Dielectric strength 1500 V AC between output/ground. Power dissipation 3.7 W. Compatible with 2-wire or 3-wire proximity sensors per IEC 60947-5-2.

Frequently asked questions

What directives does BMXDDM16022H comply with?

It complies with the 2014/35/EU Low Voltage Directive and 2014/30/EU Electromagnetic Compatibility Directive.
