Overview
The BMXERT1604H is a Schneider Modicon X80 multifunction input module, order code BMXERT1604H, providing 4 channels for time-synchronized digital/analog acquisition at 24 V DC or 125 V DC. It is designed for severe environments with conformal coating and resistance to gas, dust, salt, and mold.
This module synchronizes plant-wide events via DCF77 or IRIG-B time-code input, stamping acquired data with 1 ms resolution. Acquisition runs at 1 ms per channel with a 0.5 ms sampling duration, and the anti-bounce filter is configurable from 0 to 255 ms to suppress contact chatter on dry contacts or proximity sensors. Hot-swap capability allows module replacement without powering down the rack — critical for line-up maintenance. Sixteen input-status LEDs plus RUN, ERR, T, and I/O LEDs give immediate visual feedback on module health and signal state.
Applications
The BMXERT1604H is specified for process and utility automation in harsh environments — offshore platforms, chemical plants, water treatment, and power substations — where gas (class Gx, class 3C4), dust (class 3S4), salt (level 2), and mold (class 3B2) resistance is required. It fits Modicon X80 racks in Schneider Electric Programmable Logic Controller systems.
The BMXERT1604H carries an active lifecycle status — currently in production with no end-of-life announcement from Schneider Electric. Standard lead times apply; confirm current availability and minimum order quantities via RFQ.
