BMXFCC503 Schneider Modicon X80 Cordset, 40-way to 2×HE10, 5m, 0.324mm²

MPN BMXFCC503
Active

Schneider Electric Modicon X80 / M340, preformed cordset BMXFCC503, 40-way to 2 x HE10, 5 m cable with 0.324 mm² wire section.

$78.74 – $195.04 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

BMXFCC503 specifications
ParameterValue
Accessory separate part typePreformed cordset
Cable length5 m

Product details

Factory-assembled 40-way cordset — no field crimping

The Schneider Electric BMXFCC503 is a preformed cordset for the Modicon X80 I/O platform. It converts the 40-way module connector to two HE10 plugs over a 5 m cable with 0.324 mm² conductors — 40 wires total, split across two HE10 connectors. Built for the Telefast Advantys ABE7 sub-base system, it eliminates 40 individual field terminations with a single pre-tested assembly.

For a panel shop wiring a Modicon M340 or X80 rack, this cordset replaces a bundle of discrete wires between the I/O module and the terminal block. The HE10 connectors are keyed and latched, so the cable doesn't back out under vibration — no cable ties, no spiral wrap, no label tags.

Technical data

Parameter Value
Product range Modicon X80
Connector A 40-way (module side)
Connector B 2 × HE10 (sub-base side)
Cable length 5 m
Wire section 0.324 mm²
Number of wires 40
Target sub-base Telefast Advantys ABE7
Type Preformed cordset

What it replaces

Without the BMXFCC503, the panel builder routes 40 discrete wires from the I/O module terminal block to two HE10 connectors — roughly two hours of cutting, stripping, ferrule-crimping, and point-to-point checking. The preformed cordset is a single part number: plug it in, dress the cable, done.

Stock and ordering

We hold 29 units in position stock, $79–$195 depending on quantity. For panel-shop production runs requiring more than 20 cordsets, request a BOM line-item quote — we consolidate Modicon racks, power supplies, and cables on one proforma.
