Schneider Electric C25F44B240 — Residual Current Breakers (RCCB/RCBO)

Schneider C25F44B240 ComPacT NSX MCCB, 4-pole, 240 A, 85 kA

MPNC25F44B240
Active

Schneider C25F44B240 Compact Nsx, New Generation — now discontinued, supplied from remaining surplus and broker stock.

$3,960.36Ref. price · indicative, final on quote
Schneider Electric C25F44B240 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jun 2026

Specifications

C25F44B240 — Residual Current Protection
ParameterValue
Earth-leakage protection class / typeClass A
Trip unit technologyElectronic
Local signalling / indicationFlashing LED (green) for ready to operate LED 105 % Ir (red) for overload LED 90 % Ir (orange) for overload
C25F44B240 — Electrical Ratings
ParameterValue
Rated current (In)240 A at 40 °C
Rated operational voltage (Ue)440 V AC 50/60 Hz
Poles description4P
Neutral pole positionLeft
Network typeAC
Network frequency50/60 Hz
Rated insulation voltage (Ui)500 V AC 50/60 Hz
Rated impulse withstand voltage (Uimp)8 kV
Overvoltage categoryIV
Electrical durability20000 cycles at 440 V In/2 10000 cycles at 440 V In 10000 cycles at 690 V In/2 5000 cycles at 690 V In
Mechanical durability (operating cycles)20000 cycles
C25F44B240 — Identification
ParameterValue
Product nameComPacT NSX
Product / component typeEarth leakage circuit breaker
Product range / familyComPacT
Device short nameNSX250F
C25F44B240 — Mechanical
ParameterValue
Mounting supportBackplate
Mounting positionHorizontal and vertical Flat on the back
Control typeToggle
C25F44B240 — Environmental
ParameterValue
Operating ambient temperature-25...70 °C
Storage ambient temperature-50...85 °C
IP degree of protectionIP40 conforming to IEC 60529
Pollution degree3 conforming to IEC 60664-1
Relative humidity0...95 %
Operating altitude0...2000 m without derating 2000 m...5000 m with derating
C25F44B240 — Approvals
ParameterValue
StandardsEN/IEC 60947-2

Product details

Overview

The C25F44B240 is a 4-pole ComPacT NSX molded case circuit breaker rated 240 A at 40 °C with an 85 kA interrupting capacity at 440 V AC, fitted with a MicroLogic 4.2 AB electronic trip unit for overload, short-time, instantaneous, and earth-leakage protection.

Compared to the 3-pole C25N3 (250 A, 690 V, distribution), the C25F44B240 adds a fourth pole, drops the current rating to 240 A, and is listed for special applications rather than general distribution — choose C25N3 when the BOM calls for 3-pole distribution duty at higher voltage.

MPN
C25F44B240
