Schneider Electric C40L4 — Molded Case Circuit Breakers (MCCB)

Schneider Electric C40L4 ComPacT NSX400L, 400A Frame, 150kA/

MPNC40L4
Active

Schneider Electric ComPacT NSX400L basic frame, C40L4, 400 A frame rating at 40 °C, 4 poles, 150 kA Icu at 415 V AC, without trip unit.

$907.73 – $2,457.34Ref. price · indicative, final on quote
Schneider Electric C40L4 datasheet (PDF)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

C40L4 — Identification
ParameterValue
Product / component typeBasic frame
Device applicationDistribution
C40L4 — Electrical
ParameterValue
[In] rated current400 A at 40 °C
Breaking capacity130 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 150 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 150 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 50 kA Icu at 525 V AC 50/60 Hz conforming to IEC 60947-2 70 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2 35 kA Icu at 660/690 V AC 50/60 Hz conforming to IEC 60947-2
[Ics] rated service breaking capacity130 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 150 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 150 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 70 kA at 500 V AC 50/60 Hz conforming to IEC 60947-2 12 kA at 525 V AC 50/60 Hz conforming to IEC 60947-2 12 kA at 660/690 V AC 50/60 Hz conforming to IEC 60947-2
[Ue] rated operational voltage690 V AC 50/60 Hz conforming to IEC 60947-2
[Ui] rated insulation voltage800 V AC 50/60 Hz conforming to IEC 60947-2
C40L4 — Specifications
ParameterValue
Poles description4P
Device short nameNSX400L
StandardsEN/IEC 60947-2 UL 60947-4-1

Product details

The Schneider Electric C40L4 is a ComPacT NSX400L basic frame — a 4-pole, 400 A frame rated at 40 °C, designed for distribution applications. It carries a 150 kA Icu at 415 V AC (breaking capacity code L), with an Ics of 150 kA at 380/415 V AC, meaning it can repeatedly interrupt fault currents up to that level without needing replacement after a single event — a real advantage for high-fault locations like main switchboards or feeder breakers in industrial plants.

Mounts fixed to a backplate (not DIN rail) — the 185 mm width, 255 mm height, and 110 mm depth fit standard ComPacT NSX cutouts. The toggle control and IP40 front face (IK07 impact resistance) suit enclosed panel installation where accidental contact is a concern.

Rated insulation voltage 800 V AC, operational voltage 690 V AC. Electrical durability: 12,000 cycles at 440 V AC at In/2, 6,000 cycles at In. Mechanical durability 15,000 cycles. Class II insulation on the front face adds operator touch-safety.

Frequently asked questions

How do I get current pricing and availability for C40L4?

Submit an RFQ through this listing. The C40L4 is sourced to order through independent distribution; current pricing and availability are confirmed at quote time.

What is C40L4's listed range (ComPacT) on this component line?

The C40L4 belongs to the ComPacT range, specifically the ComPacT NSX series, as a basic frame (NSX400L).

What is C40L4's listed depth (d) (110 mm) on this component line?

The C40L4 has a depth of 110 mm, a width of 185 mm, and a height of 255 mm.

What compliance documentation does this brand provide for C40L4 (RoHS, REACH, UL, IEC)?

The C40L4 is certified to EN/IEC 60947-2 and UL 60947-4-1. It carries a Class II insulation rating on the front face and is suitable for isolation per EN/IEC 60947-2.

MPN
C40L4
