Schneider Electric CA4KN31EW3
MPNCA4KN31EW3
Obsolete
control relay, TeSys K, 4P(3NO+1NC), <=690V, 48V DC low consumption coil
$85.98Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Product range | TeSys |
| Product name | TeSys CAK |
| Device short name | CA4K |
| Product or component type | Control relay |
| Parameter | Value |
|---|---|
| Rated operational voltage [Ue] | 10 MOhm |
| Parameter | Value |
|---|---|
| Utilisation category | AC-15 DC-13 |
| Parameter | Value |
|---|---|
| Height | 2.3 in (58 mm) |
| Width | 1.8 in (45 mm) |
| Depth | 2.2 in (57 mm) |
| Parameter | Value |
|---|---|
| Operating ambient temperature | -13...122 °F (-25...50 °C) |
| Storage ambient temperature | -58...176 °F (-50...80 °C) |
| IP degree of protection | IP2X |
| Operating altitude | 6561.68 ft (2000 m) without derating |
| Protective treatment | TC IEC 60068 |
| Vibration & shock resistance | Vibrations contactor open2 Gn, 5...300 Hz IEC 60068-2-6 Vibrations contactor closed4 Gn, 5...300 Hz IEC 60068-2-6 Shocks contactor open10 Gn for 11 ms IEC 60068-2-27 Shocks contactor closed15 Gn for 11 ms IEC 60068-2-27 |
| Parameter | Value |
|---|---|
| Standards | EN/IEC 60947-5-1 GB/T 14048.5 UL 60947-5-1 CSA C22.2 No 60947-5-1 JIS C8201-5-1 |
MPN
CA4KN31EW3
