The GV2DM116B7 is a manual motor starter from Schneider's GV2 series, sized for motors drawing 9 A nominal with a 14 A magnetic trip threshold — the 9/14 A pair means the thermal overload element is set for 9 A continuous, and the short-circuit release triggers at 14 A. AC3 power ratings of 2.2 kW at 230 V, 4 kW at 400 V, and 5.5 kW at 500-690 V cover standard three-phase induction motors across European and North American line voltages; the 50/60 Hz frequency acceptance means it works on either supply without derating. The 25 A thermal current (Ith) is the unrestricted current the main poles can carry in free air — useful when the starter feeds a distribution block rather than directly into a motor.
Snap-on DIN rail mounting for 35 mm symmetrical rail per EN 60715. The GV2 body width is 45 mm — one standard modular unit — so it occupies a single 45 mm slot in the enclosure. Coil supply is 24 V AC; the control circuit draws from a separate 24 V AC source, not the motor power. For a panel-builder wiring the line: incoming power lands on the top terminals, motor leads on the bottom, auxiliary contact block clips onto the side for status feedback to the PLC.
