Overview
The LC1K06013P7 is a Schneider TeSys K three-pole contactor, rated for AC-3 and AC-3e switching at 6 A up to 440 V, with a 230 V AC 50/60 Hz coil and one normally-closed instantaneous auxiliary contact. Spring terminals accept 0.75–1.5 mm² solid or flexible wire; the unit mounts on plate or DIN rail and carries UL, CSA, CCC, and EAC certifications.
Function & operation
Rated for AC-3 and AC-3e utilization categories, the LC1K06013P7 handles motor starting and stopping at 6 A rated operational current. Electrical endurance reaches 1.3 million cycles at 6 A AC-3, with mechanical life rated at 10 million cycles. Maximum operating rate is 3600 cycles per hour. The coil draws 4.5 W holding power and dissipates 1.3 W as heat; no built-in suppressor module is included, so external suppression is required for inductive loads.
Applications
TeSys K contactors of this size are specified for controlling small motors, fans, pumps, conveyors, and lighting circuits in panel builds, OEM machinery, and commercial HVAC equipment where space is tight and spring terminals speed wiring.
Lifecycle & availability
The LC1K06013P7 is an active, current-production part within Schneider's TeSys K range. It carries multiple international certifications (CB, CCC, UL, CSA, EAC, CE, UKCA) and is compliant with EN/IEC 60947-4-1 and UL 60947-4-1 standards.
