The Schneider Electric LC3D09AM7 is a TeSys D star delta starter configured as 3 x 3P (3 NO) power poles, rated at 9 A in AC-3 utilisation category for motor control. The 220 V AC coil pulls in the contactor sequence for reduced-current starting of three-phase induction motors. This unit is pre-wired, so it arrives as a ready-to-install assembly for the starter cabinet. The IP2X front face protects against finger contact, meeting basic enclosure safety for panel mounting.
This part is marked obsolete by the manufacturer. No official successor order code appears in the lifecycle record. If you are stocking spares for a line with this starter, the critical-spare decision is straightforward: one in the cabinet before it fails. The AC-3 rating at 9 A and 220 V AC coil voltage are the binding constraints for a direct swap.
The mechanical robustness spec — 2 Gn vibration contactor open, 4 Gn closed, shocks to 15 Gn closed for 11 ms — confirms the assembly holds its contact alignment under the jolts of a starting motor or a nearby press.
