Schneider Electric LP1K09008ED — Contactors

Schneider Electric LP1K09008ED

MPNLP1K09008ED
Active

contactor, TeSys K, 4P(2NO+2NC),AC-1, 440V, 20A, 48V DC coil

Schneider Electric LP1K09008ED datasheet (PDF)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

LP1K09008ED — Identification
ParameterValue
Product / component typeContactor
Series / rangeTeSys
ApplicationResistive load
LP1K09008ED — Ratings & Performance
ParameterValue
Rated operational voltage (Ue)Power circuit Signalling circuit <= 690 V AC <= 400 Hz
Utilisation categoryAC-1
LP1K09008ED — Contacts & Poles
ParameterValue
Pole configuration4P
LP1K09008ED — Environmental
ParameterValue
IP degree of protectionIP2X
Operating altitude6561.68 ft (2000 m) without derating
Flame retardanceV1 conforming to UL 94 Requirement 2 conforming to NF F 16-101 Requirement 2 conforming to NF F 16-102
LP1K09008ED — Approvals
ParameterValue
StandardsEN/IEC 60947-4-1 EN/IEC 60947-5-1 UL 60947-4-1 UL 60947-5-1 CSA C22.2 No 60947-4-1 CSA C22.2 No 60947-5-1 GB/T 14048.4
LP1K09008ED — Mechanical
ParameterValue
Width1.8 in (45 mm)
Height2.3 in (58 mm)
Depth2.2 in (57 mm)
MPN
LP1K09008ED
