Schneider Electric LVS03154
MPNLVS03154
Active
CLASS 2 INSULATING PLATE W600/W651
$115.39Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Product / component type | Insulating plate |
| Product range | PrismaSeT |
| Product range(s) | PrismaSeT G PrismaSeT P |
| Parameter | Value |
|---|---|
| Height | 420 mm |
| Width | 600 mm |
| Component materials | Sheet steel |
| Vertical modules (50 mm) | 9 module(s): kilowatt-hour meters in 600 mm Widefloor-standing enclosure 9 module(s): kilowatt-hour meters in 600 mm Widewall-mounted enclosure 9 module(s): kilowatt-hour meters in 650 mm Widecubicle 9 module(s): kilowatt-hour meters in 555 mm WidePack enclosure 6 module(s): kilowatt-hour meters in 600 mm Widefloor-standing enclosure 6 module(s): kilowatt-hour meters in 600 mm Widewall-mounted enclosure 6 module(s): kilowatt-hour meters in 650 mm Widecubicle 6 module(s): kilowatt-hour meters in 555 mm WidePack enclosure |
| Colour | White (RAL 9003) |
| Surface finish | Matt Textured |
| Protective treatment / coating | Electrophoresis treatment and hot-polymerised polyester epoxy powder |
| Installation configuration | Floor-standing enclosure - width 600 mm Wall-mounted enclosure - width 600 mm Cubicle - width 650 mm depth 400 mm Pack enclosure - width 555 mm |
| Parameter | Value |
|---|---|
| Poles description | 2 x 4P: kilowatt-hour meters vertical installation 3 x 2P: kilowatt-hour meters vertical installation |
| Installed device | Power meters: kilowatt-hour meters - vertical installation |
| Parameter | Value |
|---|---|
| Standards | IEC 61439-2 |
| Parameter | Value |
|---|---|
| Functional unit | 600 mm PrismaSeT G floor-standing enclosure power meters kilowatt-hour meters vertical 2P 3 6 600 mm PrismaSeT G wall-mounted enclosure power meters kilowatt-hour meters vertical 2P 3 6 600 mm PrismaSeT G floor-standing enclosure power meters kilowatt-hour meters vertical 4P 2 9 600 mm PrismaSeT G wall-mounted enclosure power meters kilowatt-hour meters vertical 4P 2 9 650 mm 400 mm PrismaSeT P cubicle power meters kilowatt-hour meters vertical 2P 3 6 650 mm 400 mm PrismaSeT P cubicle power meters kilowatt-hour meters vertical 4P 2 9 |
| Accessory (separate part category) | Installation accessory |
MPN
LVS03154
