Schneider Electric METSEION92030

Schneider PowerLogic ION92030 METSEION92030 Power Quality Meter, DIN Rail, IP65

MPNMETSEION92030
Active

Schneider METSEION92030 Plc Expansion Modules — now discontinued. Supplied from remaining channel stock; full specifications, lifecycle and same-series options are below.

$4,381.50Ref. price · indicative, final on quote
Schneider Electric METSEION92030 datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

METSEION92030 key specifications
ParameterValue
Input typeVoltage (impedance 5 MOhm) External CT (impedance 0.3 mOhm)5 x
Display typeWithout Display
Metering typeDemand current I1, I2, I3, I4, I5 Peak demand currents Demand power P, Q, S Peak demand power PM, QM, SM Calculated active and reactive energy (+/- W.h, +/- VAR.h)
Type of network3P + N + E
Type of measurementVoltage sags and swells Current sags and swells Voltage Current Frequency Active and reactive power total Apparent power total Active and reactive power per phase Apparent power per phase Power factor total Power factor per phase Active and reactive energy Apparent energy Harmonic distortion (I THD & U THD)
Product or component typeEnergy and power quality meter
Isolation voltageIII400...690 V conforming to EN 61010-1:ed. 3 III347...600 V conforming to UL 61010-1:ed. 3 III347...600 V conforming to CSA C22.2 No 61010-1:ed. 3
Measurement voltage57...400 V AC 42...69 Hz between phase and neutral 100...690 V AC 42...69 Hz between phases
Supply voltage90...480 V AC 45...66 Hz +/- 10 % 90...120 V AC 400 Hz +/- 10 % 110...480 V DC +/- 10 %
Line rated current1 A 5 A
Measurement current0.01...20 A
Power quality analysisEN 50160 compliance checking IEEE 519 harmonic limit IEC 61000-4-30 class A compliance reporting IEEE 519 compliance reporting waveform capture total demand distortion total harmonic distortion up to the 63rd harmonic up to the 127th harmonic with software disturbance direction detection dip, swell and transient half cycle data acquisition transient detection (20 µs)

All specifications

METSEION92030 additional specifications
ParameterValue
Power consumption in38 VA 480 V AC
Maximum power consumption in80 VA 480 V AC
Network frequency50 Hz 60 Hz
Frequency measurement range20...450 Hz
I/O channels8 digital 30 V AC/60 V DC
IP ratingUL type 12, front
IP degree of protectionIP65 front: IP30 rear:
Communication serviceCompliant reports Power quality summary Energy report EcoStruxure Power Events Analysis SMTP e-mail notification SNMP
Communication gatewayEthernet/serial
Communication port support2 RS485 removable screw terminal block
Communication port protocolModbus RTU 2400...115200 bps - 2-wire ION 2400...115200 bps - 2-wire DNP3 2400...115200 bps - 2-wire Modbus TCP 10/100 Mbit/s ION TCP 10/100 Mbit/s DNP3 TCP 10/100 Mbit/s IEC 61850 Ethernet Modbus TCP/IP daisy chain 10/100 Mbit/s DHCP DNS DLMS
Time synchronisation protocolGPS IRIG-B NTP SNTP PTP
Mounting supportDIN rail
Installation categoryIII
Relative humidity5...95 %
Operating altitude0...9842.52 ft (0...3000 m)
Depth5.3 in (135.3 mm)
Width6.3 in (160 mm)
Height6.3 in (160 mm)
StandardsANSI C12.20 ANSI C37.90.1 IEC 61000-4-15 IEC 61000-4-30 IEC 61010-1 IEC 61326-1 IEC 61557-12 IEC 61850 IEC 62052-11 IEC 62052-31 IEC 62053-22 IEC 62053-23 IEC 62053-24 IEC 62586 UL 61010-1
RangePowerLogic
CategoryUS10PM109761
Web servicesViewing of captured waveform Web page Pass/fail report for IEEE 519 Pass/fail report for EN 50160 ITIC (CBEMA) curve SEMI curve NEMA motor derating curve Alarm notification by e-mail TLS 1.2 Push historical data via mail
CybersecuritySyslog protocol support Robust security logs Port hardening Enable/disable communication ports Hardware metrology lock
Port ethernet10/100BASE-TX 2 RJ45
Sample rate1024 samples/cycle
AccuracyClass 0.1S active energy IEC 62053-22 Class 0.1 active energy IEC 61557-12 Class 0.1 active energy ANSI C12.20 Class 0.5S reactive energy IEC 62053-24 Class 0.1 current IEC 61557-12 Class 0.1 voltage IEC 61557-12 Class 0.1 active power IEC 61557-12 Class 0.5 power factor IEC 61557-12
Data recordingTime stamping Min/max of instantaneous values User-definable data logs Continuous logging or snapshot Trending/forecasting Event logs Alarm logs Configuration change Power outage User login/logout Data logs GPS synchronisation Sequence of event recording
Market segmentData center Healthcare Semiconductor Pharmaceutical Chemical Energy Mining
Quality labelsISO 9001 ISO 14000
Memory capacity2 GB
Ethernet serviceDHCP client Device Profile Web Services (DPWS) Rapid Scanning Tree Protocol (RSTP) FTP/HTTP/HTTPS
Device short nameION92030
Ride-through time100 ms 6 cycles at 60 Hz 120 V AC typical 400 ms 24 cycles at 60 Hz 240 V AC typical 1200 ms 72 cycles at 60 Hz 480 V AC typical
Device applicationPower monitoring WAGES metering Net metering Medium voltage High voltage
Measurement accuracyVoltage +/- 0.1 % Current +/- 0.1 %
Tamperproof of settingsProtected by sealable cover
Electrical insulation classClass III EN/IEC 62052-11
Electromagnetic compatibilityEMC immunity conforming to IEC 62052-11 EMC immunity conforming to IEC 61326-1 EMC immunity conforming to IEC 61000-6-5 Electrostatic discharge immunity test conforming to IEC 61000-4-2 Immunity to radiated fields conforming to IEC 61000-4-3 Immunity to fast transients conforming to IEC 61000-4-4 Surge immunity test conforming to IEC 61000-4-5 Immunity to conducted disturbances conforming to IEC 61000-4-6 Immunity to magnetic fields at network frequency conforming to IEC 61000-4-8 Immunity to conducted disturbances - test level: 2...150 kHz conforming to CLC/TR 50579 Voltage dips and interruptions immunity test conforming to IEC 61000-4-11 Immunity to impulse waves conforming to IEC 61000-4-12 Conducted and radiated emissions conforming to EN 55011 Conducted and radiated emissions class B conforming to EN 55032 Conducted and radiated emissions class B conforming to FCC part 15 Conducted and radiated emissions class B conforming to ICES-003 Surge withstand conforming to ANSI C37.90.1 Surge withstand conforming to IEEE C37.90.1
Ambient air temperature for storage-40...185 °F (-40...85 °C)
Ambient air temperature for operation-13...158 °F (-25...70 °C)

Product details

Overview

The METSEION92030 is a Schneider Electric PowerLogic ION9000 series power quality meter, order code ION92030, designed for DIN-rail mounting with an IP65 enclosure. It provides 8 digital inputs (30 V AC/60 V DC) and 4 form C relay outputs, and supports simultaneous communication via Modbus RTU, Modbus TCP, DNP3, IEC 61850, and ION protocols over dual RJ45 Ethernet ports. The meter operates on a 480 V supply with a rated voltage of 400 V, consumes 38 W, and offers 0.1% accuracy with 1024 samples/cycle for power quality analysis.

Communication

The METSEION92030 supports Modbus RTU, ION, and DNP3 over RS-485 at 2400–115200 bps, plus Modbus TCP, ION TCP, DNP3 TCP, and IEC 61850 over 10/100 Mbit/s Ethernet. All protocols can be active simultaneously; no single-protocol selection is required at commissioning. Ethernet services include DHCP client, FTP, HTTP/HTTPS, and Rapid Spanning Tree Protocol (RSTP) for network redundancy.

Compliance

The meter is IEC 61000-4-30 Class A compliant for power quality measurements and generates EN 50160 compliance reports. It also checks IEEE 519 harmonic limits and captures waveform data for analysis. Additional standards include IEC 61010-1, IEC 61326-1, IEC 61557-12, IEC 61850, ANSI C12.20, and UL 61010-1.

Selection notes

With 0.1% accuracy and 1024 samples/cycle, the METSEION92030 suits applications requiring precise harmonic analysis up to the 127th order. Ride-through times range from 100 ms at 120 V AC to 1200 ms at 480 V AC, ensuring operation through brief supply dips. The headless design (no display) is operated via embedded web services for waveform viewing, pass/fail reports for IEEE 519 and EN 50160, and alarm notifications by email. No separate display module is required for setup or ongoing monitoring.

Power & Mounting

Supply voltage is 480 V AC; rated voltage is 400 V AC. Power consumption is 38 W.

Memory & Data Recording

The meter includes 2 GB of memory for data logs, event logs, alarm logs, and waveform capture. It supports user-definable continuous or snapshot logging, trending/forecasting, and sequence of event recording with GPS synchronisation.

Lifecycle

MPN
METSEION92030
