Compact HMI for legacy Modicon panels
The TM172DCLWTHP: This is a Schneider Modicon M171/M172 display module – 3.4 in wide, 4.7 in tall, flush-mount form. Color touchscreen LCD at 320 × 240 pixels, built-in NTC 10k type 2 temperature probe (±0.1 °C accuracy in the 40–50 °C range) and a humidity probe (10–90 % RH without condensation). It's a sealed-front panel component for controlling line temperature and humidity directly from the HMI, no extra sensor interface needed. Runs on 24 V AC/DC, draws 1.3 W.
Lifecycle reality – obsolete, but we've got it
Compliance paperwork covers both hemispheres: IEC 60950-1, EN 55024, EN 55032, CSA C22.2 No 24, UL 873, plus the EU EMC and low-voltage directives. For cross-border shipping or plant audits, that's all in the box.
