Schneider Electric TM172EVEV1B

Schneider TM172EVEV1B Modicon M172 Expansion Unit, 1 CAN Por

MPNTM172EVEV1B
Active

Schneider Electric Modicon M172 Expansion Unit, TM172EVEV1B, 1 CAN port, 24 V AC/DC, DIN rail, IP20.

$96.09 – $102.87Ref. price · indicative, final on quote
Schneider Electric TM172EVEV1B datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

TM172EVEV1B key specifications
ParameterValue
Display typeWithout Display
Range of productModicon M171/M172
Product or component typeExpansion unit
Supply voltage24 V +/- 10 % AC 20...38 V DC
Power consumption in18 W 24 V DC
Maximum power consumption in23 VA 24 V AC
IP degree of protectionIP20
Mounting supportDIN rail
Pollution degree2
Relative humidity5...95 % non-condensing
Depth2.4 in (60 mm)
Width1.4 in (36 mm)

All specifications

TM172EVEV1B additional specifications
ParameterValue
Height4.4 in (113 mm)
StandardsEN 60730-1 EN 60730-2-9 UL 60730-1 UL 60730-2-9 CAN/CSA-E60730-1 CSA E60730-2-9 IEC 6100-4-2 IEC 6100-4-3 IEC 6100-4-4 IEC 6100-4-5 IEC 6100-4-6 IEC 6100-4-11 EN 60068-2-27 EN 60068-2-6 Fc UL94 (material V0)
CategoryUS1PC1222537
Number of port1 CAN port - 1 removable 3-way screw connector
Overvoltage categoryI
Ambient air temperature for storage-22...158 °F (-30...70 °C)
Ambient air temperature for operation-4...149 °F (-20...65 °C)

Product details

Integration Brief

The TM172EVEV1B is a Modicon M172 expansion unit with a single CAN port on a removable 3-way screw connector. It accepts 24 V +/- 10 % AC or 20…38 V DC, drawing 18 W (23 VA on AC). No display on this variant — it fits where operator readout isn't needed and you just need the CAN interface.

Mounting & Power

DIN rail mount, 4.4 x 1.4 x 2.4 in (113 x 36 x 60 mm). IP20 — strictly indoor cabinet use. Pollution degree 2, overvoltage category I. Ambient range is -20…65 °C operating, -30…70 °C storage, with 5…95 % non-condensing humidity. Power budget: 18 W at 24 V DC or 23 VA at 24 V AC — well within a typical panel supply capacity.

Frequently asked questions

What compliance standards does the TM172EVEV1B meet?

It meets EN 60730-1, EN 60730-2-9, UL 60730-1, UL 60730-2-9, CAN/CSA-E60730-1, CSA E60730-2-9, plus IEC 61000-4-2/3/4/5/6/11 for EMC, and EN 60068-2-27/2-6 for mechanical endurance.

MPN
TM172EVEV1B
