Schneider Electric TM5C24D12R
MPNTM5C24D12R
Active
COMPACT I/O EXPANSION BLOCK, MOD
$49.09Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Range of product | Modicon TM5 |
| Product or component type | Compact I/O expansion block |
| Discrete input voltage | 24 V DC 20.4...28.8 V) |
| Discrete output voltage | 30 V DC 24...36 V)relay 240 V AC 184...276 V)AC |
| Voltage state 0 guaranteed | <= 5 V |
| Discrete output current | 2 A per output |
| Minimum switching current | 10 mA 5 V DC |
| Typical current consumption | 68 mA 5 V DC 165 mA 24 V DC for inputs/outputs |
| Power dissipation in | 4.3 W |
| Enclosure material | Plastic |
| IP degree of protection | IP20 |
| Mounting support | DIN rail |
All specifications
| Parameter | Value |
|---|---|
| Electrical connection | Removable spring terminal block |
| Response time | = 15 V |
| Pollution degree | 2 |
| Shock resistance | 15 gn 11 ms |
| Relative humidity | 5...95 % without condensation |
| Operating altitude | 0...6561.68 ft (0...2000 m) |
| Vibration resistance | 1 gn 8.4...150 Hz) on DIN rail 3.5 mm 5...8.4 Hz) on DIN rail |
| Color | White |
| Depth | 3.0 in (75 mm) |
| Width | 0.5 in (12.5 mm) |
| Height | 3.9 in (99 mm) |
| Mechanical durability | 20000000 cycles |
| Standards | CSA C22.2 No 213 CSA C22.2 No 142 IEC 61131-2 UL 508 |
| Marking | CE |
| Category | US1PC1222532 |
| Input filtering | <= 25 ms configurable by software |
| Input impedance | 6.4 kOhm |
| Local signalling | 24 LEDs (green) for input status 4 LEDs (green) for power supply 4 LEDs (red) for power supply 12 LEDs (yellow) for output status |
| Number of modules | Digital input 2 x 12 Relay output 2 x 6 |
| Input (output number) | 36 |
| Discrete input logic | Sink |
| Discrete input number | 24 |
| Discrete output logic | Source or sink |
| Discrete output number | 12 relay at 30 V DC at 240 V AC |
| Isolation between channels and bus | 500 Vrms AC |
| Ambient air temperature for storage | -40...158 °F (-40...70 °C) |
| Input (output number of splitter box) | 24 I + 12 O |
| Ambient air temperature for operation | 14...122 °F (-10...50 °C) vertical installation) 14...140 °F (-10...60 °C) horizontal installation) |
MPN
TM5C24D12R
