Overview
The TM5SDI6U is a Schneider Modicon TM5 digital input module, order code TM5SDI6U, with 6 discrete inputs rated at 120 V AC and a shock rating of 15 gn for 11 ms. The module mounts on a DIN rail, uses screw terminals, and is rated IP20 for in-cabinet use. It provides 1500 V AC isolation between channel and bus. Compatible with Modicon M258 logic controllers and LMC058 motion controllers, the TM5SDI6U carries CE, cULus, CSA, and C-Tick certifications.
Applications
As a Modicon TM5 digital input module, the TM5SDI6U connects limit switches, pushbuttons, and proximity sensors to a PLC or motion controller in packaging machines, conveyor lines, and material-handling cells.
The 6 discrete inputs accept 120 V AC signals, allowing direct connection of AC sensors and switches without an intermediate relay. A green LED per input indicates status for quick troubleshooting. Hardware input filtering from state 0 to state 1 is ≤ 15 ms, with a configurable software filter up to 25 ms, reducing false triggering from electrical noise. Rated for 15 gn shock for 11 ms, the module withstands vibration and impact common on moving machinery.
