Schneider Electric TM5SDO2TAFS

Schneider TM5SDO2TAFS Safety Output Module, 2A/Ch, SIL 3

MPN TM5SDO2TAFS
Active

Schneider Electric Modicon TM5, safety DC discrete output module, TM5SDO2TAFS, 2 digital outputs, 24V 2A, SIL 3, PL e.

$234.95 – $419.00 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

TM5SDO2TAFS specifications
ParameterValue
Main product or component typeSafety dc discrete output module
Frequency<= 500 Hz resistive
IP ratingIP20
Temp storage max70 °C
Temp storage min-40 °C
Temp operating max50 °C
Temp operating min-10 °C
Storage temperature-40...158 °F (-40...70 °C)
Pollution degree2
Depth3.0 in (75 mm)
Width1.0 in (25 mm)
Height3.9 in (99 mm)
Discrete output logicPositive logic (source)
Operating temperature14...122 °F (-10...50 °C) vertical installation) 14...131 °F (-10...55 °C) horizontal installation)

Product details

TM5SDO2TAFS is the safety output slice for a Modicon TM5 rack — two source outputs, 24 V DC at 2 A each, switching up to 500 Hz on resistive loads. SIL 3 per IEC 61508 and PL e per EN 13849-1 so this is for certified safety loops, not general-purpose I/O. MTTFd over 100 years and PFD below 1E-5 means it's built to satisfy the high-integrity channel requirements.

Slim slice: 25 mm wide, 75 mm deep, 99 mm tall — one slot on the TM5 backplane. IP20 so cabinet-only. Horizontal mounting gets the full -10 to 55 °C range; vertical knocks it to 50 °C. Shock rated 15 gn for 11 ms, vibration 1 gn on DIN rail. Two LEDs per output for safety status, two more for supply rails — quick visual on the panel walk.

MPN
TM5SDO2TAFS
