Schneider TM5SE2IC01024 Modicon TM5 Counter Module 100 kHz

Name: TM5SE2IC01024
Brand: Schneider Electric
SKU: TM5SE2IC01024
Availability: LimitedAvailability
Author: Calibration Cal

Specifications

TM5SE2IC01024 key specifications
Parameter	Value
Encoder type	2 incremental encoders
Range of product	Modicon TM5
Product or component type	Counter module
Surge withstand	0.5 kV differential mode IEC 61000-4-5 1 kV common mode IEC 61000-4-5
DC supply voltage	24 V
Discrete input voltage	24 V DC
Current consumption	2 mA 5 V DC bus 63 mA 24 V DC input/output
Discrete input current	1.3 mA 24 V
Maximum power dissipation in	1.51 W
Counting frequency	100 kHz
IP degree of protection	IP20IEC 61131-2
Pollution degree	2 IEC 60664

All specifications

TM5SE2IC01024 additional specifications
Parameter	Value
Shock resistance	15 gn 11 ms
Storage altitude	0...9842.5 ft (0...3000 m)
Relative humidity	5...95 % without condensation
Operating altitude	0...6561.68 ft (0...2000 m)
Vibration resistance	1 gn 8.4...150 Hz DIN rail 3.5 mm 5...8.4 Hz DIN rail
Depth	3.0 in (75 mm)
Width	0.5 in (12.5 mm)
Height	3.9 in (99 mm)
Standards	UL 508 CSA C22.2 No 142 CSA C22.2 No 213 IEC 61131-2
Marking	CE
Category	US1PC1222532
Isolation	500 Vrms AC insulation between channel and bus
Input resistance	18.4 kOhm
Function of module	2 x 24 V DC auxiliary inputs 24 V DC encoder power supply
Maximum cycle time	2 ms
Input compatibility	2 incremental encoders (24 V)
Discrete input logic	Sink
Discrete input number	2
Counter inputs resolution	16 bits/32 bits
Product specific application	Period measurement Frequency generator Frequency meter Downcounting Upcounting Axis following with encoder
Electromagnetic compatibility	EN/IEC 61000-4-6
Resistance to fast transients	1 kV IEC 61000-4-4 I/O) 1 kV IEC 61000-4-4 shielded cable) 2 kV IEC 61000-4-4 power lines)
Disturbance radiated (conducted)	CISPR 11
Ambient air temperature for storage	-13...158 °F (-25...70 °C)
Resistance to electromagnetic fields	0.9 V/m (1 V/m) 2...2.7 GHz IEC 61000-4-3 9.1 V/m (10 V/m) 80...2000 MHz IEC 61000-4-3
Ambient air temperature for operation	32...131 °F (0...55 °C) without derating horizontal installation) 32...140 °F (0...60 °C) with derating factor horizontal installation) 32...122 °F (0...50 °C) vertical installation)
Resistance to electrostatic discharge	4 kV on contact IEC 61000-4-2 8 kV in air IEC 61000-4-2

Product details

The TM5SE2IC01024 is a Modicon TM5 counter module accepting two incremental encoders at 24 VDC, with a counting frequency of 100 kHz. The 16/32-bit counters support period measurement, frequency generation, up/down counting, and axis following. Isolation between each channel and the backplane bus is rated 500 Vrms AC per the spec table, which keeps common-mode noise off the controller side.

Mounting and power budget

The module footprint is 12.5 mm wide by 75 mm deep by 99 mm tall, taking one slot on the DIN-rail assembly. Current consumption from the 5 V DC backplane is 2 mA; the I/O side draws 63 mA at 24 V DC. Total power dissipation is 1.51 W, well within the typical TM5 rack thermal budget. The 24 V DC encoder supply is sourced through the module's own terminals, so additional external supply wiring is eliminated for standard 24 V encoders.

Frequently asked questions

What are the key ratings of the TM5SE2IC01024?

It accepts two 24 VDC incremental encoders at a counting frequency up to 100 kHz, with 16/32-bit counter resolution. Channel-to-bus isolation is 500 Vrms AC. Power consumption is 2 mA from the 5 V bus plus 63 mA at 24 V for the I/O side.

What compliance certifications does the TM5SE2IC01024 carry?

CE marking, UL 508, CSA C22.2 No. 142 and 213, IEC 61131-2, and pollution degree 2 per IEC 60664. EMC compliance includes EN/IEC 61000-4-6 and CISPR 11.
