Schneider Electric TM5SPS10FS

Schneider TM5SPS10FS Power Distribution Module, 24V DC, 10A

MPN TM5SPS10FS
Obsolete

Schneider Modicon TM5 power distribution module, TM5SPS10FS, 24 V DC, 10 A I/O power segment, IP20.

$248.92 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

TM5SPS10FS specifications
ParameterValue
Main product or component typePower distribution module
IP ratingIP20
Temp storage max70 °C
Temp storage min-25 °C
Temp operating max55 °C
Temp operating min-10 °C
Storage temperature-13...158 °F (-25...70 °C)
Pollution degree2
Depth4.1 in (105 mm)
Width2.4 in (60 mm)
Height1.2 in (30 mm)
Operating temperature14...131 °F (-10...55 °C) without derating horizontal installation) 131...140 °F (55...60 °C) with derating factor horizontal installation) 14...122 °F (-10...50 °C) vertical installation)

Product details

What it does in the panel

The TM5SPS10FS: This little red module is the power bus for a TM5 I/O rack — takes a 24 V DC supply and splits it out to the I/O slices down the line, rated a solid 10 A on that I/O power segment. The 25 mA it draws for its own brains won't crimp your power budget, and the 0.8 W dissipation means it stays cool even stuffed between a bunch of input cards.

Mounting and hookup

Clips onto a DIN rail — you'll need a 10 A external fuse on the incoming side, per the spec. The screw/spring terminal block takes the field wiring. Vibration rating at 1 gn on the rail and a 15 gn shock pulse (11 ms) mean it'll hold up in a cabinet next to contactors cycling all day. Operating range is -10 to 55 °C horizontal (60 °C with derating) or -10 to 50 °C vertical — plenty of headroom for a standard enclosure.

MPN
TM5SPS10FS
