The Schneider Electric VW3E1159R020 is a hybrid cable in the PacDrive 3 range, purpose-built to connect a Lexium 62 connection module to an HCN-2 adapter. At 2 m (6.6 ft), it's the standard length for linking the drive module to the motor feedback adapter in a cabinet layout where the adapter sits a short distance from the drive — typical in multi-axis machine builds where the HCN-2 adapter is mounted near the motor cable entry point.
Listed as Active in production. The VW3E1159R020 is a current catalog item in the PacDrive 3 ecosystem, not a phase-out or NRND part. No cross-reference or direct substitute exists in the PacDrive 3 range — the 2 m length is the standard, and the cable is the only hybrid link between the Lexium 62 connection module and the HCN-2 adapter.
Fit Note for the Integrator
This cable carries both power and feedback signals in a single sheath — hybrid construction. That means one cable run from the Lexium 62 connection module to the HCN-2 adapter, rather than separate motor power and encoder cables. The 2 m length suits a standard cabinet depth where the adapter is mounted on a sub-panel or DIN rail within arm's reach of the drive module. If the adapter sits farther away, the PacDrive 3 range offers other lengths; the VW3E1159R020 is the 2 m variant.
