The WB1GA145 is a replacement coil from the TeSys range, designed specifically for Schneider Electric CV1B and CV3B contactors. It's a low-consumption AC/DC coil, meaning it handles both supply types and draws minimal holding current once the contactor is sealed — useful in panels where heat buildup or power supply loading is a concern.
Schneider Electric TeSys WB1GA145 Contactor Coil, AC/DC, Obs
MPNWB1GA145
Obsolete
Schneider Electric TeSys range, WB1GA145 contactor coil, AC/DC control circuit, low consumption type, for CV1B/CV3B contactors.
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Product range | TeSys |
| Product or component type | Contactor coil |
| Parameter | Value |
|---|---|
| Control circuit type | AC/DC |
| Parameter | Value |
|---|---|
| Coil type | Low consumption |
Product details
Frequently asked questions
What is the closest pin-compatible alternative to WB1GA145?
No official successor or direct replacement order code has been published by Schneider. The part is sourced through surplus or new-old-stock channels.
What range does WB1GA145 belong to?
It belongs to the Schneider Electric TeSys range.
What contactors does the WB1GA145 coil fit?
It is designed for CV1B and CV3B contactors.
MPN
WB1GA145
