Schneider Electric XB4BL4325 — Emergency Stop Pushbuttons

Schneider Electric XB4BL4325

MPNXB4BL4325
Obsolete

Harmony XB4, Push button, metal, projecting, red, Ø22, spring return, marked O, 1 NO + 1 NC

Schneider Electric XB4BL4325 datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

Identification

XB4BL4325 — Identification
ParameterValue
Product typePush-button
Product rangeHarmony XB4
Device short nameXB4
Operator profileRed projecting, O (white)

Function & Operation

XB4BL4325 — Function & Operation
ParameterValue
Signaling head shapeRound

Switching & Contacts

XB4BL4325 — Switching & Contacts
ParameterValue
Mechanical durability (cycles)10000000 cycles

Mechanical

XB4BL4325 — Mechanical
ParameterValue
Mounting diameter22 mm
Height47 mm
Width30 mm

Environmental

XB4BL4325 — Environmental
ParameterValue
IP protection ratingIP66 conforming to IEC 60529 IP67 IP69 IP69K
Operating temperature range-40...70 °C
Storage temperature range-40...70 °C
Vibration resistance5 gn (f= 2...500 Hz) conforming to IEC 60068-2-6
Shock resistance30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27 50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27

Approvals & Standards

XB4BL4325 — Approvals & Standards
ParameterValue
Standards / approvalsEN/IEC 60947-5-5 JIS C8201-5-1 EN/IEC 60947-5-1 CSA C22.2 No 14 EN/IEC 60947-1 EN/IEC 60947-5-4 UL 508 JIS C8201-1
