Schneider Electric XB4BW35B1 — Emergency Stop Pushbuttons

Schneider Electric XB4BW35B1

MPNXB4BW35B1
Active

Illuminated push button, Harmony XB4, orange flush, 22mm, spring return, 1NO, 24V

Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

XB4BW35B1 — Identification
ParameterValue
Product typeIlluminated push-button
Product rangeHarmony XB4
Device short nameXB4
Operator profileOrange flush
XB4BW35B1 — Function & Operation
ParameterValue
Signaling head shapeRound
XB4BW35B1 — Switching & Contacts
ParameterValue
Mechanical durability (cycles)10000000 cycles
XB4BW35B1 — Mechanical
ParameterValue
Mounting diameter22.5 mm
Height47 mm
Width30 mm
XB4BW35B1 — Environmental
ParameterValue
IP protection ratingIP66 conforming to IEC 60529 IP67 IP69 IP69K
Operating temperature range-40...70 °C
Storage temperature range-40...70 °C
Vibration resistance5 gn (f= 2...500 Hz) conforming to IEC 60068-2-6
Shock resistance30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27 50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27
XB4BW35B1 — Approvals & Standards
ParameterValue
Standards / approvalsIEC 60947-5-5 IEC 60947-5-1 UL 508 CSA C22.2 No 14 IEC 60947-5-4 IEC 60947-1 JIS C8201-5-1 JIS C8201-1
MPN
XB4BW35B1
