Schneider Electric XB7EVFD1LC — Emergency Stop Pushbuttons

Schneider Electric XB7EVFD1LC

MPNXB7EVFD1LC
Obsolete

round pilot light Ø 22 - white - integral LED - 110 V DC - screw clamp terminals

Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

XB7EVFD1LC — Identification
ParameterValue
Product rangeHarmony XB7
Device short nameXB7
XB7EVFD1LC — Function & Operation
ParameterValue
Signaling head shapeRound
XB7EVFD1LC — Mechanical
ParameterValue
Mounting diameter22 mm
Height29 mm
Width29 mm
XB7EVFD1LC — Environmental
ParameterValue
IP protection ratingIP20 (rear face) conforming to IEC 60529 IP40 (front face) conforming to IEC 60529
Operating temperature range-25...70 °C
Storage temperature range-40...80 °C
Vibration resistance5 gn (f= 2...500 Hz) conforming to IEC 60068-2-6
Shock resistance50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27 30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27
XB7EVFD1LC — Approvals & Standards
ParameterValue
Standards / approvalsIEC 60947-1 IEC 60947-5-1 GB 14048.5 GB 14048.1
MPN
XB7EVFD1LC
