Schneider Electric XCKP2102M12 — Limit Switches

Telemecanique XCKP2102M12 Limit Switch, Roller Plunger, 3A @

MPNXCKP2102M12

Telemecanique Sensors XCKP Series, XCKP2102M12, Limit Switch, Roller Plunger, Plastic, 3 A @ 240 V AC/DC, IP66, IP67, M12 Connector.

$17.78Ref. price · indicative, final on quote
Schneider Electric XCKP2102M12 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

XCKP2102M12 key specifications
ParameterValue
SeriesXCKP
ActuationRoller Plunger
Body material typeNon-Metallic
Contact form1NO/1NC
IP ratingIP66; IP67
NEMA enclosure rating1; 2; 4; 6; 12; 13
Mounting styleSurface
Number of mounting holes2
Mounting hole diameter - NEW0.17 in
Mounting hole horizontal center to center distance19 mm
Electrical connection4-Pin M12 Connector
Operating temperature - maximum158 °F

All specifications

XCKP2102M12 additional specifications
ParameterValue
Operating temperature - minimum-13 °F
Body depth1.18 in
Body width1.22 in
Body height2.56 in
Arm materialMetal
Roller width0.14 in
Body materialPlastic
Overall depth1.18 in
Overall width1.22 in
Overall height2.56 in
Roller materialSteel
StandardsCE; CSA; UL Listed
Display qty1
Actuator styleRoller Plunger
Actuator length0.8 in
Roller diameter0.46 in
Display sell UOMEA
AC contact rating3 A @ 240 V
Actuator locationTop
DC contact rating3 A @ 240 V
Boot sealed actuatorNo Boot Included
Directional movementLinear
Resistance propertiesShock Resistant; Vibration Resistant
Operating force - maximum12 N
Operating torque - maximum1.6 in-lb

Product details

The Telemecanique Sensors XCKP2102M12 is a roller-plunger limit switch from the XCKP series, built for position sensing on automated machinery — conveyors, packaging lines, material-handling gates. It carries a 1NO/1NC contact block rated 3 A at 240 V AC or DC, so it handles both control-voltage signals and modest pilot-duty loads directly without an interposing relay.

Environmental sealing and approvals

Rated IP66 and IP67, so the switch body and actuator seal against hose-directed water and temporary immersion — suitable for washdown zones in food processing or outdoor conveyor transfer points. The NEMA enclosure ratings (1, 2, 4, 6, 12, 13) confirm it meets North American indoor/outdoor enclosure standards for dust, dripping water, and corrosion resistance. Listed to CE, CSA, and UL standards — accepted across European and North American installations without additional agency review. The 4-pin M12 connector (micro-change style) is the standard quick-disconnect for industrial sensors; replacement cables are widely stocked.

Frequently asked questions

What are the key ratings for this limit switch?

The contacts are rated 3 A at 240 V AC and 3 A at 240 V DC. The roller plunger requires a maximum 12 N operating force. The switch is sealed to IP66 and IP67, and carries UL, CSA, and CE approvals.

What connector does the XCKP2102M12 use?

It terminates in a 4-pin M12 connector, the standard micro-change style for industrial sensors and limit switches.

What is the closest alternative to the XCKP2102M12 in the same family?

Within the XCKP series, the closest peer is the XCKP2102P12, which shares the same roller plunger actuator, contact form, and M12 connector but uses a metal body instead of plastic. The choice between them depends on whether the application needs the impact resistance of a metal housing or the corrosion resistance of a non-metallic one.
