Schneider Electric XCKT2102G11
MPNXCKT2102G11
SQUARE D XCKT2102G11: LIMIT SWITCH 240VAC 3A PLAST XCKT
$112.59Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
| Parameter | Value |
|---|---|
| Type | COMPACT, MODULAR |
| Operation type | SNAP ACTION |
| Connection type | PG11 CABLE GLAND/SCREW CLAMP TERMINAL |
| Actuator (Head type) | STEEL TOP ROLLER PLUNGER |
| Contact configuration | 1NO-1NC |
| Enclosure | NEMA 1/2/4/6/12/13, IP66, IP67 |
| Operating temperature | -13 TO 158 DEG F |
| Body material | WIDE PLASTIC |
| Approval | UL 508, CSA C22.2 |
| Model | XCKT |
| Category | General Duty Limit Switches |
| Manufacturer | Square D Co. |
All specifications+8 ▾
| Parameter | Value |
|---|---|
| Sub-Category | General/Heavy Duty Limit Switch |
| Contact rating | 240 VAC 10 AMPERE, 250 VDC 0.27 AMPERE |
| Operating force | 318 LB-INCH |
| Manufacturer brand | Square D Co. |
| Differential travel | 1.5 MM |
| Product description | Telemecanique XCKT2102G11 Limit Switch 240Vac 3A Plastic Xckt |
| Additional information | APPLICABLE STANDARD EN/IEC 60204-1, EN/IEC 60947-5-1 |
| Full technical description | Compact, Modular Type; 1NO-1NC Contact Configuration; PG11 Cable Gland/Screw Clamp Terminal Connection Type; Snap Action Operation Type; 240 VAC 10 Ampere, 250 VDC 0.27 Ampere Contact Rating; UL 508, CSA C22.2 Approval; NEMA 1/2/4/6/12/13, IP66, IP67 Enclosure; Wide Plastic Body Material; -13 to 158 Deg F Operating Temperature; 318 lb-Inch Operating Force; 1.5 mm Differential Travel; Steel Top Roller Plunger Actuator/Head Type; OSISWITCH[R] Brand; Applicable Standard En/Iec 60204-1, En/Iec 60947-5-1; XCKT Model |
MPN
XCKT2102G11
