Analog Integration via M12 Connector
When wiring analog pressure feedback into a PLC input card, the 4-20 mA output of the Schneider XMLBS04B2S11 pressure switch connects directly via its M12 connector, eliminating the need for signal conditioning. The 24 V AC/DC supply works with both panel and field power architectures.
Environmental and Mechanical Durability
Rated IP65 and built with a diaphragm operator, the XMLBS04B2S11 withstands washdown environments and operates from -25°C to 70°C. The G1/4 female port and screw terminals simplify field wiring.
Pressure Range and Accuracy
The pressure range of 3.63 to 58.02 PSI (25 to 400 kPa) covers common pneumatic monitoring tasks with ±2% accuracy. Maximum overpressure capability of 543.89 PSI (3750 kPa) protects against spikes.
Lifecycle and Availability
With an active lifecycle status and high market demand, the XMLBS04B2S11 is readily available through standard distribution channels.
Frequently asked questions
What is the output signal of the XMLBS04B2S11?
The output is a 4-20 mA analog signal.
What is the IP rating?
IP65.
