Schneider Electric XS130BLPAL2 — Proximity Sensors

Telemecanique XS130BLPAL2 Inductive Proximity Sensor, M30, P

MPNXS130BLPAL2

Telemecanique Sensors XS1 Series, XS130BLPAL2, Inductive Cylindrical Proximity Sensor, M30 Threaded, Shielded, PNP, NO, 10 mm, 12-24 VDC, 200 mA, IP67, Prewired 2 m Cable.

$9.14Ref. price · indicative, final on quote
Schneider Electric XS130BLPAL2 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

XS130BLPAL2 — Identification
ParameterValue
SeriesXS1
XS130BLPAL2 — Sensing
ParameterValue
Sensing distance, max. (alt.)10 mm
Sensing methodInductive
Sensing-face shieldingShielded
XS130BLPAL2 — Electrical
ParameterValue
Supply voltageNot Rated ; 12-24V DC
AC supply voltage ratingNot Rated
DC supply voltage rating12-24V DC
Number of wires3
Electrical connectionBare Wire
Electrical installation typePrewired Cable
XS130BLPAL2 — Output
ParameterValue
Output circuit contact formNO
Output circuit typePNP
Includes indicator lightsIndicator Lights Included
Output circuitPNP
XS130BLPAL2 — Mechanical
ParameterValue
Body styleCylindrical
Overall height57 mm
Body materialBrass
XS130BLPAL2 — Environmental
ParameterValue
Operating temperature, max. (alt.)158 °F
Operating temperature, min. (alt.)-13 °F
IP ratingIP67
XS130BLPAL2 — Approvals
ParameterValue
Standards / certificationsCE; CSA; RoHS; UL Listed

Product details

The XS130BLPAL2 is a current-production M30 threaded inductive proximity sensor from the XS1 series. It delivers a 10 mm shielded sensing range with a PNP normally-open output, running on 12-24 VDC and rated for 200 mA continuous load. The brass body with nickel plating and IP67 / NEMA 4X rating makes it a direct fit for washdown zones and oily environments where plastic housings degrade.

Mounts in a standard M30 threaded hole with the supplied locknuts. The 2 m prewired cable with bare ends lands directly in a terminal block — no separate connector body to order. Shielded face limits the sensing zone to the front, so side-by-side mounting without crosstalk is practical at standard separation. PNP output sinks 200 mA, enough for a PLC input or a small relay coil without an interposing interface.

Frequently asked questions

What is the closest functional second-source — XS9E11RPBL01M12?

The XS9E11RPBL01M12 is a plastic rectangular sensor with the same 10 mm range, PNP output, and IP67 rating, but it uses an M12 connector instead of a prewired cable and switches at 800 Hz versus the XS130BLPAL2's unspecified frequency. It will not drop into the same M30 threaded hole without an adapter, and the connector adds a separate cable purchase.

What compliance documentation does this sensor provide?

It carries CE, CSA, RoHS, and UL Listing marks — sufficient for most industrial control panels and MRO stockroom audits.
