Schneider Electric XS1N12PC410D — Proximity Sensors

Telemecanique Sensors XS1N12PC410D Inductive Proximity, PNP,

MPNXS1N12PC410D

Telemecanique Sensors, Series XS1, Inductive Cylindrical Proximity Sensor, 17 mm diameter, Shielded, Sensing Distance 2 mm, PNP, 4-Wire, M12 Connector, IP65/IP67/IP69K.

Schneider Electric XS1N12PC410D datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

XS1N12PC410D — Identification
ParameterValue
SeriesXS1
XS1N12PC410D — Sensing
ParameterValue
Sensing distance, max. (alt.)2 mm
Sensing methodInductive
Sensing-face shieldingShielded
XS1N12PC410D — Electrical
ParameterValue
Supply voltageNot Rated ; 12-24V DC
AC supply voltage ratingNot Rated
DC supply voltage rating12-24V DC
Number of wires4
Electrical connectionM12
Electrical installation typeDirect Connector
XS1N12PC410D — Output
ParameterValue
Output circuit contact formNO/NC
Output circuit typePNP
Includes indicator lightsIndicator Lights Included
Output circuitPNP
XS1N12PC410D — Mechanical
ParameterValue
Body styleCylindrical
Overall height50 mm
Body materialBrass
XS1N12PC410D — Environmental
ParameterValue
Operating temperature, max. (alt.)158 °F
Operating temperature, min. (alt.)-13 °F
IP ratingIP65; IP67; IP69K
XS1N12PC410D — Approvals
ParameterValue
Standards / certificationsCE; CSA; E2; TUV; UL Listed

Product details

The XS1N12PC410D is a Telemecanique Sensors inductive proximity sensor from the XS1 series, designed for metal target detection in industrial automation. It is a shielded cylindrical sensor with a 17 mm diameter body and a 2 mm sensing distance, rated for PNP output (NO/NC programmable) via a 4-pin M12 connector. Per the specification, the sensor provides overload protection, reverse polarity protection, and short circuit protection, making it robust for direct connection to PLC inputs or industrial loads. The nickel-plated brass body and IP65, IP67, and IP69K ratings allow installation in washdown or high-pressure cleaning environments. Operating temperature range is -13 °F to 158 °F. Supply voltage is 12-24 V DC.

Frequently asked questions

What compliance certifications does the XS1N12PC410D carry?

The sensor is listed with CE, CSA, TUV, and UL certifications. These are the compliance marks available in the product specification.

What is the sensing distance and output type?

Maximum sensing distance is 2 mm (shielded). The output circuit is PNP with NO/NC programmable contact form, 4-wire configuration.

What is the environmental protection rating?

Rated IP65, IP67, and IP69K, suitable for high-pressure, high-temperature washdown environments.
