The XS218AAPAM12: M18 cylindrical inductive sensor from the XS2 family, unshielded face for a full 15 mm sensing range on steel. PNP normally-open output, three-wire DC with integral M12 connector — standard wiring for industrial discrete I/O. Rated IP67 and IP69K plus NEMA 4X, so it survives high-pressure washdown in food or chemical plant areas. Supply spans 12 to 48 V DC, output sinks up to 200 mA. The built-in indicator light gives quick visual confirmation during commissioning.
Sourcing & lifecycle
Lifecycle status is current. Compliance documentation covers CCC, CE, CSA, RoHS, UL Listed.
Integration notes
Unshielded face: maximum sensing distance 15 mm, minimum 8 mm. M18 threaded nickel-plated PPS body with 4-pin M12 connector. Operating temperature -13 to 185 °F covers most indoor and outdoor environments. The M12 connector mates with standard three-pole cordsets; verify pin 1 brown (V+), pin 4 black (NO output), pin 3 blue (GND).
