The Telemecanique XS5 series XS508B1PAM8 is an M8 cylindrical shielded inductive proximity sensor with a PNP normally open output. Sensing distance is 2 mm at the face, supplied at 12-24 V DC and rated for loads up to 200 mA. The stainless steel body (grade 303) with nickel plating and IP67 / NEMA 4X enclosure makes it a candidate for washdown or mild chemical exposure in food or packaging lines.
What the ratings mean for fit
Shielded construction means the sensing face is flush-mountable in metal; no derating for flush install. The M8 threaded barrel requires a standard 8 mm hole. Wire count is three, output is PNP, and the electrical connection is a direct M8 connector, not a pigtail — panel side must have a mating M8 cordset. The LED indicator gives a quick visual confirmation of target presence.
Compliance documentation
Carries CE, CSA, RoHS, and UL Listed marks plus NEMA 4X enclosure rating. The stainless steel body with nickel plating supports corrosive environment applications. RoHS compliance is factory-stated; REACH documentation should be available through the Telemecanique / Schneider portal.
