The XS612B1NAL2: Brass-bodied inductive sensor from the XS6 series, built for washdown and submerged mounting. Shielded M12 body lets you flush-mount it in steel without derating the 4 mm sensing range. NPN normally-open output sinks up to 200 mA at 12-48 VDC, and the 2-meter prewired cable terminates into your control panel or junction box. Rated IP68 and IP69K, so it survives submersion and high-pressure hot-water washdown cycles common in food, beverage, and chemical processing lines. Nickel-plated brass body resists corrosion far better than the plastic housing of the XS9 series, and the NEMA 4X rating confirms enclosure-level protection against hose-down and corrosion.
Telemecanique XS612B1NAL2 Inductive Sensor, M12, NPN, 4mm, I
MPNXS612B1NAL2
Telemecanique XS6 series, XS612B1NAL2 inductive cylindrical proximity sensor, M12 threaded shielded, NPN NO output, 4 mm sensing distance, 12-48V DC, 2 m cable, IP68/IP69K brass body.
$16.51Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
Identification
| Parameter | Value |
|---|---|
| Series | XS6 |
Sensing
| Parameter | Value |
|---|---|
| Sensing distance, max. (alt.) | 4 mm |
| Sensing method | Inductive |
| Sensing-face shielding | Shielded |
Electrical
| Parameter | Value |
|---|---|
| Supply voltage | Not Rated ; 12-48V DC |
| AC supply voltage rating | Not Rated |
| DC supply voltage rating | 12-48V DC |
| Number of wires | 3 |
| Electrical connection | Bare Wire |
| Electrical installation type | Prewired Cable |
Output
| Parameter | Value |
|---|---|
| Output circuit contact form | NO |
| Output circuit type | NPN |
| Includes indicator lights | Indicator Lights Included |
| Output circuit | NPN |
Mechanical
| Parameter | Value |
|---|---|
| Body style | Cylindrical |
| Overall height | 54 mm |
| Body material | Brass |
Environmental
| Parameter | Value |
|---|---|
| Operating temperature, max. (alt.) | 158 °F |
| Operating temperature, min. (alt.) | -13 °F |
| IP rating | IP68; IP69K |
Approvals
| Parameter | Value |
|---|---|
| Standards / certifications | CE; CSA; E2; RoHS; UL Listed |
Product details
Frequently asked questions
What is the closest functional second-source — XS9E11RPBL01M12?
The XS9E11RPBL01M12 is a different product: plastic rectangular body, IP67, PNP NC output, 10 mm sensing distance, and M12 connector. It cannot substitute without rewiring and changing the mounting approach.
What are the key ratings and compliance approvals for this sensor?
The sensor carries CE, CSA, RoHS, and UL Listing approvals. Key ratings include: IP68/IP69K enclosure, NPN NO output, 200 mA load maximum, 12-48 VDC supply, 4 mm shielded sensing distance, and a nickel-plated brass M12 body.
MPN
XS612B1NAL2
