M18 shielded proximity sensor for industrial washdown zones
The XS618B1MAL5 is a brass-bodied M18 threaded inductive sensor rated IP68 and IP69K, making it a direct fit for high-pressure washdown environments where NEMA 4X enclosures are specified. Shielded sensing face permits flush mounting in metal panels without range derating. Supply voltage covers 24-240V AC or DC, so it lands on global machines without transformer selection. Output is NO, 2-wire, with a maximum switching current of 300 mA — suitable for direct PLC input or small relay loads. The 5 m prewired cable with bare ends simplifies panel termination; no separate connector or junction box needed.
Form-factor comparison vs rectangular sibling XS8D1A1MAL2
The XS8D1A1MAL2 is a rectangular PBT sensor with 60 mm sensing range and a 2 m cable, no indicator light. The XS618B1MAL5 is cylindrical M18, shielded, with 8 mm range, a 5 m cable, and an integral LED indicator. Different mounting footprints and sensing performance mean the XS618 cannot drop into a panel designed for XS8D1A1MAL2 without mechanical rework.
