Schneider Electric XS630B1PBM12 — Proximity Sensors

XS630B1PBM12 Inductive Prox, PNP NC, M12, 15mm, IP69K

MPNXS630B1PBM12

Telemecanique Sensors XS6 series, XS630B1PBM12, inductive cylindrical proximity sensor, M30 threaded shield, PNP NC output, M12 connector, 12-48 VDC, sensing range 15 mm.

$21.59Ref. price · indicative, final on quote
Schneider Electric XS630B1PBM12 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

XS630B1PBM12 — Identification
ParameterValue
SeriesXS6
XS630B1PBM12 — Sensing
ParameterValue
Sensing distance, max. (alt.)15 mm
Sensing methodInductive
Sensing-face shieldingShielded
XS630B1PBM12 — Electrical
ParameterValue
Supply voltageNot Rated ; 12-48V DC
AC supply voltage ratingNot Rated
DC supply voltage rating12-48V DC
Number of wires3
Electrical connectionM12
Electrical installation typeDirect Connector
XS630B1PBM12 — Output
ParameterValue
Output circuit contact formNC
Output circuit typePNP
Includes indicator lightsIndicator Lights Included
Output circuitPNP
XS630B1PBM12 — Mechanical
ParameterValue
Body styleCylindrical
Overall height74 mm
Body materialBrass
XS630B1PBM12 — Environmental
ParameterValue
Operating temperature, max. (alt.)158 °F
Operating temperature, min. (alt.)-13 °F
IP ratingIP67; IP69K
XS630B1PBM12 — Approvals
ParameterValue
Standards / certificationsCE; CSA; E2; RoHS; UL Listed

Product details

M30 threaded, PNP NC, M12 connector

The XS630B1PBM12: Inductive proximity sensor from the XS6 series. M30 shielded face delivers a 15 mm sensing distance on standard steel targets. Output is PNP normally-closed, rated 200 mA, running on 12-48 VDC. Built-in overload, reverse polarity, and short circuit protection – no external suppression needed for simple DC loads. IP67 and IP69K rated – survives high-pressure washdown cycles. Brass housing, nickel plated. 4-pin M12 connector; mates with standard pre-terminated cables.

XSAV02801 swap? Not directly

The XSAV02801 from the XSA series matches the M30 thread and 15 mm shielded sensing range, but it's a 2-wire device running on 24-210 VDC with a prewired 2 m cable. XS630B1PBM12 uses a separate 3-wire PNP output and an M12 connector, plus a 12-48 VDC supply. Dropping one into a panel built for the other means changing the wiring harness and supply voltage – not a pin-to-pin swap.

Cylindrical brass body, 74 mm height, M30 threaded. M12 connector, 4 pins, PNP output.

Frequently asked questions

What is the closest functional second-source, XSAV02801?

XSAV02801 shares M30 thread and 15 mm shielded range but uses a different output circuit (2-wire, 24-210 VDC, prewired cable). It is not a direct electrical or mechanical drop-in without rewiring and supply changes.

What is the series for XS630B1PBM12?

Series XS6.

What features are included?

Overload protection, reverse polarity protection, and short circuit protection.

What compliance documentation does this provide?

CE, CSA, RoHS, and UL Listed certifications are declared.
