The Telemecanique XS7C2A1PAM12 is a 40×40×70 mm block inductive proximity sensor from the XS7 family. It detects ferrous targets at 15 mm, flush mounted, and switches a PNP normally-open output at up to 300 Hz DC. Rated 12–24 VDC, 200 mA, with a 4-pin M12 male connector. The PBT housing carries IP65/67/69, so it handles washdown environments common in machine-tool coolant areas.
Cross-checking against the XS4P18AB110
If you came here looking to cross a cylindrical 8 mm sensor like the XS4P18AB110, stop: that sensor is a different form factor (24 mm cylindrical, 8 mm shielded, 24–48 VDC, analog output). The XS7C2A1PAM12 is rectangular, 15 mm, discrete PNP, and runs on 12–24 VDC. No drop-in replacement — rewiring and re-mounting required.
Lifecycle is current — no phase-out or last-time-buy window. Approvals: UL, CSA, CE. No RoHS or REACH declaration in available data; request compliance docs with RFQ.
