Sensor Integration Note
The XS8C2A1NCM12 is a 20 mm shielded inductive sensor in a rectangular PBT body. It runs on 12–48 V DC and outputs an NPN signal—typical for PLC sinking inputs. Built-in overload, reverse polarity, and short circuit protection cover common field faults.
Same-Series Sibling Check
The closest peer in the XS8 family is XS8D1A1MAL2. Both are rectangular inductive sensors, but that model is a 2-wire AC/DC unit with a 60 mm sensing range, prewired cable (2 m), and no indicator light. It also skips the IP69K rating (IP68 max). If your panel is wired for DC NPN 3-wire with an M12 connector, the XS8D1A1MAL2 will not drop in without changing the output circuit, wiring, and mounting clearance for the larger face.
Mechanical & Wiring Profile
Body dimensions are 70 mm wide × 40 mm deep × 40 mm tall, with a shielded sensing face that allows flush mounting without derating the 20 mm rated range. M12 connector, 4-pin, wired for a 3-wire NPN output, and operating temperature range is –13 °F to +158 °F.
