The XS8C4A1MPN12: Rectangular shielded inductive sensor from the XS8 family, sized 40x40x117mm. Rated IP65, IP67, and IP69K — the last means it survives high-pressure, high-temp washdown cycles, so it lives on food, beverage, and pharmaceutical lines. Supply swings 24-240V AC or DC, making it simple to drop into existing 24VDC or 120VAC control circuits without an extra power supply. Output is programmable NO or NC, max 300mA. That covers direct drive of small relays, PLC inputs, or solenoid valves — keep the load under 300mA and you're fine. Sensing distance is 20mm on shielded (flush) mount, so it won't false-trigger on adjacent metal.
What the Enclosure Ratings Actually Mean
Rated IP69K for high-pressure washdown environments. PBT housing resists caustic chemicals. Screw clamp terminals on the bare wire pigtail include an indicator LED. Two-wire design.
