The Telemecanique XS8C4A4PCM12 is a rectangular inductive proximity sensor in the XS8 series, with a PNP output, unshielded sensing face, and a 40 mm sensing distance. Rated IP65, IP67, and IP69K, so it survives hot washdown in food or beverage lines. The PBT body handles high-pressure cleaning without degradation. Supply is 12–48 VDC, load current up to 200 mA, with an M12 4-pin connector. Output is programmable NO/NC via the wiring configuration.
Comparing to the XSDA600519H7 panel install
If you're replacing or cross-referencing an XSDA600519H7 (XSD series, 80×80×40 mm, screw clamp terminals, 12–240V AC), the XS8C4A4PCM12 is not a mechanical or electrical drop-in. The XS8 body measures 40×40×117 mm, uses an M12 connector for DC-only supply, and has a different mounting hole pattern. Rewiring and possibly re-drilling a panel would be required. The XS9E11RPBL01M12 (XS9 series, 26×13×40 mm, 4-pin M12, PNP-NC, 10 mm range) shares the connector type and voltage range but offers only a 10 mm sensing distance and normally-closed output, versus the 40 mm NO/NC of this XS8. Neither is a functional second-source without engineering review.
Compliance documentation covers CCC, CE, CSA, RoHS, and UL Listing. Available upon request if not included in the shipment.
